China 1ton 2ton 3ton Comfortable Mini Excavator Mini Digger 4ton 5ton Compact

Product Description

Product Description
Small/mini excavators/mini digger are widely used in greenhouse orchards, mountain ditches, rural renovation, indoor and outdoor, construction projects, road finishing and other working conditions.
Generally, it is composed of power device, transmission device, walking device and working device. Principle: Use the bucket to excavate the material above or below the bearing surface, and load it into the transport vehicle or the earth-moving machine unloaded to the stockyard. A self-propelled mining machine that uses a bucket to shovel exfoliated material or minerals from the working face and transport it to a discharge location for unloading. History: It has been more than 130 years since the first manual excavator came out. During this period, it has experienced from steam-driven bucket rotary excavator to electric drive and internal combustion engine-driven rotary excavator, and fully automatic hydraulic excavator using electromechanical-hydraulic integration technology. gradual development process.
Due to the application of hydraulic technology, there was a mounted excavator equipped with a hydraulic backhoe on a tractor in the 1940s. In the early and mid-1950s, a trailed azimuth hydraulic excavator and a crawler full hydraulic excavator were successively developed. . The initial trial-produced hydraulic excavator adopts the hydraulic technology of aircraft and machine tools, lacks hydraulic components suitable for various working conditions of the excavator, the manufacturing quality is not stable enough, and the supporting parts are not complete. Since the 1960s, hydraulic excavators have entered a stage of promotion and vigorous development. The number of excavator manufacturers and varieties in various countries has increased rapidly, and the output has soared. From 1968 to 1970, the output of hydraulic excavators accounted for 83% of the total output of excavators, which was close to 100%.
YANMAR engine, low noise, low fuel consumption, big torque. Zero tail, swing boom and rubber tracks. Expandable tracks suitable for working in narrow spaces. 3 Cylinder Yanmar Engine, Natchi Pump, Eaton Drives, Hydrocontrol Valve Block Optional hydraulic quick hitch, hammer, ripper, thumb and auger. Various buckets can be selected. In cab heater, radio and fan.
Parameters Of SOLID CT18 Rural Transformation Small Mini Excavator Easy Operation Excavator Digging Machine

Performance Parameters	Overall Weight: 1.8T	Bucket Capacity: 0.04m3
	Rated Power: 11.2/2400kW/rpm	Travel Speed (High/Low): 2.8 km/h
	Rotation Speed: 10.5rpm	Climbing Ability: 58%/30°
	Ground Pressure: 28kPa	Bucket Excavation Force: 14.8kN
	Arm Excavation Force: 10.2kN
Machine Dimensions	Total Length (during transport): 3867mm	Total Width: 1000mm
	Total Height (top of the boom): 1185mm	Total Height (top of the cabin): 2313mm
	Track Width: 230mm	Track Gauge: 760mm
	Minimum Ground Clearance: 175mm	Rear Swing Radius: 1072mm
	Track Ground Length: 1210mm	Track Length: 1588mm
Operating Range	Maximum Digging Height: 3327mm	Maximum Unloading Height: 2323mm
	Maximum Digging Depth: 2110mm	Maximum Digging Reach: 3900mm
	Minimum Swing Radius: 1575mm	Steering Angle (Left/Right): 56°/52°

Detailed Photos


Features

SOLID Heavy Industries presents a newly designed multi-purpose compact excavator. It combines energy efficiency, reliability, and comfort in one, offering flexible operation with low noise. This excavator is widely used in construction sites, landscaping, municipal, and urban development in tight spaces.
Key Features
Efficient and Reliable
· Equipped with a Japanese Yanmar engine, compliant with Euro V and EPA4 emission standards, ensuring the machine's reliability even in harsh working conditions.
· Standard high-precision air filters and dual-stage diesel filtration guarantee the reliable operation of the engine.
Sensitive and Stable
· Features hydraulic components exclusively provided by Cater Heavy Industries for more responsive control, enhanced system stability, and increased reliability.
Convenient and Flexible
· The chassis is extendable, with a foldable dozer blade, offering flexible working width adjustments.
· The working device is adjustable, suitable for various edges and corners.
· Hydraulic quick-change connections facilitate the installation of various attachments.
·The upward-hinged overall rear cover allows for routine maintenance work to be carried out with ease.
Safe and Comfortable
· The entire machine complies with CE certification requirements.
· The design includes driver cabin and canopy for rollover protection and falling object protection, meeting TOPS and FOPS certification requirements, ensuring a higher level of safety.
· Some cabin models are equipped with a heater, enhancing comfort during winter operations.
Rated Excavator
Rated Products
Packaging & Shipping
Company Profile
SOLID was founded in 2008 year. Since then, SOLID has stood at the forefront of the Chinese construction machinery industry and developed into one of the domestic industry's largest, most influential, and most competitive enterprise groups with the most complete product varieties and series.SOLID is ranked 65th in the list of China's Top 500 Companies, 44th in the list of China's Top 100 Manufacturing Enterprises, and 2ND in the list of China's Top 100 Machinery Manufacturers. SOLID is dedicated to its core value of "Taking Great Responsibilities, Acting With Great Morals, and Making Great Achievements" and its corporate spirit of being "Rigorous, Practical, Progressive, and Creative" in order to keep moving towards its ultimate goal of becoming a leading world-class enterprise capable of creating real value.SOLID mainly supply Hoisting machinery, MiningMachinery Machinery, , Excavators, Loaders, Road Machinery, Piling Machinery, Non-Excavation Machinery, Concrete Machinery, Special Vehicle, Aerial Working Equipment, Sanitation Machinery, Fire-fighting Machinery, Tunnel Machinery, Resource Exploration Machinery, Port Machinery and so onSOLID products, including mechanical vibratory road rolls, mini excavators and motor graders,mini digging, have successfully participated in the construction of the largest railway project in the Philippines, thanks to their outstanding performance and comprehensive after-sales service. These three types of machines have contributed to the project's progress in an organized manner. During our on-site visits to customers, they expressed that SOLID products are reliable in quality, and the compact excavator equipped with a hydraulic breaker delivers excellent impact force. This effectively ensures the project's advancement and contributes to its completion within the expected timeframe, providing additional momentum to the development of local livelihood projects.
