Yx50-330-990 Floor Decking Roof Roll Forming Machine

Product Description

YX50-330-990 ROLL FORMING MACHINE FOR FLOOR DECKING
If customization:Yes
Series:Roll former for decking
Type:YX50-330-990 Decking
Overall Dimensions: 22860mm×4500mm×1600mm
Total G.W.: 16000KG
Brand:Erudite roll forming
YX50-330-990 roll forming machine for floor decking
Profile:
The Chart of Process Flow
Technical Parameters
The main technical parameters are for your inference only.
Only if you provide the profile required or the real objects of sectional materials,
and we will offer the accurate parameters.

(1) 5Tons un-coiler
Description	There are different choices, please turn to the catalogue of un-coiler
( 2) The general machine parameter
Suitable roll forming material	Color steel sheet or galvanized steel sheet
Thickness	0.8-1.2mm
Feeding width	1219mm
Frame design	Wall-plate-frame-design /Strong-stand-frame-design
Roll stages	26-28 stages
Material of forming roller	45# steel with forge treatment, CNC lathes, Hard Chrome Coated Embossing rollers made from GCr15+heat treatment, Hard Chrome Coated
Shafts Diameter	Φ95mm
Main motor power	18.5KW*2 with reducer
Max. Line speed of roll former	12-15m/min (Higher speed is available, depends on the specification required by the buyer)
Hydraulic group power	5.5KW
Material of cutting blade	Cr12, heat treatment
Electric Standard	220V /60Hz/3PH or as the customer's requirements
Machine Dimensions	22860mm×4500mm×1600
Major Color of Machine Painted	RAL 5015 (Blue) or as per customer's requirements
(3) PLC Control system
PLC	Siemens brand
Touch Screen	Siemens brand
Inverter	Shihlin or Panasonic brand
Encoder	Omron brand
(4) Product rack
Description	un-powered, 6 meters long
(5) Option: Hydraulic pre-shearing device Pneumatic Stacker CE certificate Pl refer to the attached pictures for details
(6)About us
Please visit the web site: eruditerfm.en.made-in-china.com for detailed information

FAQ
Where is the ERUDITE products market?
ERUDITE products sell well not only in the domestic market but also other countries and regions such as in Asia, Africa,Erurope,South America,Australia etc, formed into EERUDITE special sales network throughout the world.
Is the ERUDITE company a trade company or manufacture company ?
Erudite company is manufacturer and developed for near 10 years as one of more influential companies in the manufacture industry of cold rolling mills /roll formig line.
How does Erudite company provide the oversea after-service?
If installation is needed, Erudite company will dispatch a technician to the buyer's factory abroad to assist regulating the machine.
How many months for ERUDITE company machine guaranteed ?
In correct operation & maintaining ,the machine is guaranteed for 12 months since leaving factory.
What's ERUDITE company terms of payment ?
-FOB contract:
30% payment by T/T is required as deposit within ten (10) business days since the contract signing date. 70% balance payment is required by T/T prior to shipment.
-CFR or CIF contract:
30% payment by T/T is required as deposit within ten (10) business days since the contract signing date. 70% balance payment is required by T/T prior to shipment or by irrevocable and non-transferable L/C at sight, to be established at least one month before shipment.
