Cylindrical Centerless Grinding Machine Model M1083b Dia. 150mm Shaft Outer Diameter Rough Grinding
| US$120,000.00-210,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
M1083B
Type
Centerless Grinding Machine
Processing Object
1
Abrasives
Grinding Wheel
Controlling Mode
Artificial
Automatic Grade
Manual
Cylindrical Grinder Type
Universal Cylindrical Grinder
Precision
Precision
Certification
CE, ISO 9001
Condition
New
Accuracy
0.01mm
Grinding Wheel
600*200*305mm
Max Diameter
150mm
Transport Package
Wooden Case
Specification
2650*1500*1800mm
Trademark
PHISONG
Origin
China
HS Code
8460291100
Production Capacity
100
Packaging & Delivery
Package Size
280.00cm * 160.00cm * 190.00cm
Package Gross Weight
7500.000kg
Product Description
Precise Centerless Grinder Model M1083B
1. Salient features:
1.1 For Grinding wheel and Regulating wheel
1.1.2.The grinding wheel's outer diameter designed as 600mm, with strong
cutting force.
1.1.3.The grinding wheel designed in cantilever type, and its spindle adopted
five-plate long bearing bushed static-hydrodynamical oil film bearing.
1.1.4.The roller guide regulating wheel feed slide moves quickly and accurately,
and with long service life.
1.2.Electric.
1.2.1.AC frequency converter is used for regulating wheel speed control.
1.2.2.Hydraulic transmission & stepless speed regulation are adopted on
regulating wheel & grinding wheel dresser.
1.3. Machine body and design
1.3.1.The machine equipped with plunge-in unit.
1.3.2. Iron casting with high rigidity, natural aging.
2. Technical Data:
| In-feed Grinding | Dia. | 10-150mm |
| Length | 190mm | |
| Through grinding | Dia. | 10-150mm |
| GW SPEC. (O.D.*width*I.D.) | P600*200*305mm | |
| RW SPEC.(O.D.*width*I.D.) | PDA350*200*203mm | |
| GW Speed | 1115r/min | |
| RW Speed (stepless) | 10-200r/min | |
| Swiveling Angle of RW | Vertical | -2°~ +5° |
| Horizontal | 0°~ +3° | |
| GW min feeding amount | 0.01mm | |
| GW dresser min feeding amount | 0.015mm | |
| Height from center line of GW & RW to work rest | 285mm | |
| GW Motor | 22kw | |
| RW Motor | 3kw | |
| Power Supply | 3N 50HZ 380V | |
| Dimension(L*W*H) | 2650*1500*1800mm | |
| Machine Weight | About 7000kg | |
| Accuracy (standard bars D10mm, L50mm) | Roundness | 0.002mm |
| Cylindricity | 0.003mm | |
| Roughness | Ra.0.32μm | |
3. Main Accessories
| Name | QTY | Unit | Brand |
| Grinding wheel motor | 1 | pc | Wannan |
| Regulating wheel motor | 1 | pc | Wannan |
| Low-voltage apparatus | 1 | set | Chint |
| Converter for RW | 1 | set | Huichuan |
