Honey Liquid Bag Multi Line Sachet Packing Machine

Product Description

Product Description
Application
Honey Liquid Bag Multi Line Sachet Packing Machine
    Apply to the industries such as medical , food ,chemical and etc. Suitable for the granule packaging such as  seeds, rice, spice granule, and etc.
Reference Sample

Multi Lane Packing Machine Specifications
Model	DS-M4L	DS-M6L	DS-M8L	DS-M10L
Lane Number	4 lanes	6 lanes	8 lanes	10 lanes
Bag Width	12-90mm	12-60mm	12-45mm	16-35mm
Bag Length	40-165mm	40-165mm	40-165mm	40-165mm
Packing Speed	30-50 Bags/Min/Lane
Control System	PLC + Servo + Touch Screen
Sealing type	Back sealing/ stick bag
Power supply	back sealing/ stick bag
Measuring range	1--35ml/lane

Product Description
Detailed Images
Film Making Former ,Change it to do different bag width    With vertical sealing and horizontal sealing part
   Smart Touch Screen( Easy Operation )                                                                 Electrical Parts (Easy Control)
Main Features1. Multi lanes machine can produce multi lanes bags at same time.
2. Machine main function: automatic split film at right position, liquid measuring and filling, multi lanes bag form fill seal, cutting, sensor tracking, counting capacity.
3. Other function: Emergency stop, set capacity to auto stop machine, count capacity and Zero the count, ready bag output, manual test machine each step etc.
4. Stainless steel contact part and the machine outer shell, high feature for liquid running environment.
5. High precision photocell sensor for auto tracking the eye mark printing on the film roll, so cut each bag at precisely position.
6. PLC controller, high function and control the whole machine's work steps.
Our Company&Workshop
   Foshan Dession Packaging Machinery Co.,Ltd is located in nanhai district, foshan,It is a collection of research, production, sales and after-sales service as one of the production-oriented enterprises.Machines are widely used in food, articles for daily use, hardware industrial products, medical supplies, hotel one-time items, etc. Along with the continuous development of science and technology, the level of automatic packing machinel is higher, scope will be wider.
Certifications
Our Service
*Pre-Sales Service
1.Inquiry and consulting support,professional packing solution for free.
2.Machine videos for your reference.
3.Sample testing support.
4.View our Factory.
*After-sale Service
1. Manules / Videos of machine installation, adjusting, setting, maintenance are available for you.
2. If any problems happend and you can not find out the solutions, Telecom or Online face to face communication available 24 hours.
3. Dssion engineers & technician are available send to your countries for services if you agree pay the expenditure.
4. The machine will have 1 year warranty of machine,2 years warranty of electric part. During the warranty year if any of the parts broken not by man-made. We will free charge to replace the new one to you. The warranty will begin after the machine send out we received the B/L.
Packing & Delivery

Packaging (Using plywood case)
Size	(L)1100* (W) 755* (H)1540MM
Gross Weight	350KG
Packaging Details	1)Dedust & Cleaning 2) Lubricate Drive Parts 3) Divide Machine Into Modules 4) Wrap Modules With Plastic Film 5) Packing Modules into Plywood Cases 6)Mark Shipping Mark In The Cases If any special requirements, we will pack it as requested..

FAQ
For any Questions1. Q : Can your machine meet our needs well, how to choose the proper settings ?
A : Dear, before quoting, please kindly consult us and providing:
1.The packaging pruduct name;
2.Packaging bag size(Length/Width) or the weight of each packaging bag;
3. Pacaging speed;
4.Bag types showing above or your own design;
it will be more easier for us to recommend the most suitable packing machine for you to make your cost to the minimum.
2. Q: Do you have manual or operation video for us to know more about the machine?
A : Yes, not only manual or operation video, 3D drawing also available to make as per your design,also the video we can make of testing the material from our packaging machine if your packing goods easier for us to find from our local market.
3. Q: How can I trust you for the first time business ?
A: Please note our above business license and certificate. And if you don't trust us, then we can use Alibaba Trade Assurance service. it will protect your money during the whole stage of transaction.
4. Q: Can you explain me the whole transaction process ?
A: Both sides reached cooperation intention -
---- Signed the Contract
---- Arrange the deposit to factory
---- Factory arrange production
---- Testing&detecting the machine before shipping
---- Inspection by customer or third agent or through online
---- Arrange the balance payment
---- Confirm the shipping details then delivery
Guild customer setting after machine arrived.
5.Q: How do we contact you?
A: There is a contact information in the bottom of this page. Please leave massage and click "send". you also can contact us through Email, wechat, viber, skype, whatsapp, QQ, Line, phone and etc.
