Recycled Plastic PET Bottle Label Removing Machine

Product Description

Recycled Plastic PET Bottle Label Removing Machine Product Description
High Output Plastic PET Bottle Label Remover Machine is necessary part of PET bottle recycling line. It can remove the label automatically. This label remover machine can remove label without water, it can save a lot of water, reduce the water waste. The blade can change very easy, design stable speed, needn't to convert speed, easily operating. PET bottle label remover machine complete change the previous way of removing the label by manual work. Because it is greatly improving the productivity and reducing the labor intensity.
Features
1. Blades made by alloyed steel for long time use
2. Blades fixed by screws on the rotor, easy to adjust and change.
3. Blades and friction gap can be automatically adjusted according to the size of bottles which achieving best label-peeling effect.
4. There are several individual small doors on both sides of the machine for easy open, which is convenient to clean and maintain the inside parts, saving time and labor cost.
5. Bearing house installed outside the machine no dirty goes inside.
6. The rotor feeder part with screw so no bottles pop out.
7. Machine is made by solid frame; there is visual window on the top easy to check inside and cleaning
8. The bottom with mesh to drain out liquid that contained in bottles.
Detailed Photos
Label Remover Machine
Used to remove the labels from the bottle and separate label out from bottles.Label remove effective: > 98%
Dry working without water
Using the seal ball bearing with NSK brand.
Bearing house is outside of machine body no dirty goes inside for long time use.
Label Remover Machine
Machine made by solid frame, on the top there is glass window easy to clean the machine and checking inside.The machine bottom
with holes to drain out liquid which contained in the bottles, good for machine use
Rotary Blade
Blade made by alloyed steel for long time use.
Blade is fixed by screw on the rotor easy to adjustable and changeable.Rotor blades: 96 PCS for LMD-15
Fixed Blade
Blade material: D2
Channel Iron: Stainless Steel
Label Remover Rotor
The rotor feeder part with screw so no bottles pop out.

Product Parameters

Model	LMD-7.5	LMD-15	LMD-22	LMD-30	LMD-37
Main motor power	7.5KW	15KW	22KW	30KW	37KW
Label suction fan power	4KW	4KW+4KW	4KW+4KW	4KW+4KW	4KW+4KW
Label scrape power	1.5KW	1.5KW	1.5KW	1.5KW	1.5KW
Capacity	300-500kg/hr	1500kg/hr	2000kg/hr	3000kg/hr	4000kg/hr
Rotor diameter	630mm	630mm	720mm	720mm	720mm
Rotor length	3500mm	4500mm	4500mm	4500mm	4500mm
Label separation rate	>98%	>98%	>98%	>98%	>98%
Cap separation rate	30-50%	30-50%	30-50%	30-50%	30-50%
Machine size (L*W*H)	4x1x1.8m	5x1x1.8m	5x1x1.8m	5x1x1.8m	6.3x1x2.8m
Machine weight	2000kgs	2800kgs	2800kgs	2800kgs	4000kgs
