Yuyun Sanhe Poultry Equipment Hanging Double Safenet Ventilation Exhaust Fan Ceiling Mount Animal Husbandry Livestock Machinery
Basic Info.
Model NO.
DJF(b)-1
Usage
Ventilation and Cooling Equipment
Application
Cow
Power Source
Electric
Certification
ISO9001:2008, CE
Condition
New
Warranty
2 Years
Frame Material
Galvanized Sheet
Zinc Coating
275g/Sqm
Blade Number
6PCS
Drive
Belt Drive
Speed
1 Speed
Power Supply
Electric
Voltage
380/220V/Customized
Frequency
50/60Hz
Motor
Chinese High Quality Motor
Model
Poultry Hanging Fan
Installation Type
Hanging Ceiling Mounted
Apply
Cow Cattle Dairy Barn Farm Farming House Shed
Products Name
Double Mesh Hanging Ventilation Exhaust Fan
Transport Package
Standard Paper Carton
Specification
International standard
Trademark
Yuyun Sanhe
Origin
Shandong China
HS Code
8414809090
Production Capacity
300PCS/Day
Product Description
DJF(b)-1 Series Hanging Exhaust FanProduct Application: DJF(b)-1 Series Hanging Double Mesh Ventilation Exhaust Fan is widely used in the cow cattle dairy barn chicken house for air ventilation and cooling.
Technical Parameter:
| Model | Drive | Blades Diameter (mm) | Blades Rotational Speed | Motor Rotational Speed | Air Flow (m³/h) | Noise Decibels (db) | Input Power (W) | Voltage (V) | Frequency (HZ) | Outline Size (H*W*T) (mm) |
| DJF(b)-1-900 | Belt | 750 | 630rpm | 1400rpm | 28000 | ≤65 | 370 | 220 / 380/ Customized | 50 / 60 | 900*900*420 |
| DJF(b)-1-1000 | Belt | 900 | 610rpm | 1400rpm | 30000 | ≤70 | 750 | 1000*1000*420 | ||
| DJF(b)-1-1100 | Belt | 1000 | 600rpm | 1400rpm | 32500 | ≤70 | 750 | 1100*1100*420 | ||
| DJF(b)-1-1220 | Belt | 1100 | 460rpm | 1400rpm | 38000 | ≤70 | 750 | 1220*1220*420 | ||
| DJF(b)-1-1380 | Belt | 1270 | 439rpm | 1400rpm | 44000 | ≤70 | 1100 | 1380*1380*420 | ||
| DJF(b)-1-1530 | Belt | 1400 | 325rpm | 1400rpm | 55800 | ≤70 | 1500 | 1530*1530*420 |
Product Description:
| Fan blades 1. Material : 430 stainless steel, thickness 1.2mm 2. Diameter: 1270mm Advantage: Large air flow, no deformation, no fracture, no dust, attractive and durable. Note: Blade material also have galvanized sheet, aluminum alloy for option | |
| Belt Pulley 1. Material: High strength aluminum-magnesium alloy by die-casting. 2. Blast-sanding treatment, eliminate internal stress to improve its own rigidity and stability Advantage: Light weight, Low vibration ,attractive appearance. | |
| Bearing Imported double-row bearing with special waterproof design. Advantage: High strength, low noise, free maintenance and long service life. | |
| Hanging Rings Four hanging rings are added Advantage: Convenient to install and adjust the angle to reach excellent performance. | |
| Belt Brand: Mitsuboshi belt (Japanese) Type: A type Advantage: Famous brand, Long service life, maintenance free | |
| Round Frame Material: Hot-dip galvanized sheet with zinc thickness of 275g/sqm Advantage: Extremely improves the anti-corrosion performance. | |
| | Motor 1. Brand: Chinese famous motor, Siemens motor, ABB motor and WEG motor 2. Motor Protection Grade: IP55 3. Isulation Class: F grade Advantage: Motor voltage and frequency can be customized. Chinese famous motor OEM by special design for fan, the first put in the phase lack protection device which would power off when shortage of electricity. |
About our Company
Shandong Yuyun Sanhe Machinery Co.,Ltd is the biggest and the most professional manufacturer of ventilation equipment in
China,equipped with the most advanced CNC production lines and laser cutting machines, top quality level in the industry.
