Wheel-Belt Excavator National Machinery Factory Production and Sales of Large Excavators
| US$67,311.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
MS81A
Type
Wheel Excavator
Usage
GM Excavator
Bucket
Grab Shovel
Transmission
Hydraulic Transmission
Drive Type
Electric Drive
Bucket Capacity
0.1~0.5m³
Size
Large-Scale
Certification
CE, ISO9001: 2000
Condition
New
Machine Weight
6600kg
Total Length
6380mm
Total Width
2150mm
Total Height
2827mm
Wheelbase
2400mm
Mini Clearance Ground
217mm
Rated Power
55/2500kw/Rpm
Maximum Torque
269/1610
Rated Flow
135L/Min
Transport Package
Blacksmithing Frame
Specification
17000kg
Trademark
Mingsin
Origin
China
HS Code
8429521200
Production Capacity
5000 Sets/Month
Product Description
Product DescriptionFeatures:
1) stepless automatic transmission, four-wheel drive, four-wheel hydraulic oil brake, adapt to all road conditions.
2) Enhanced front thrust belt balance cylinder and back leg design, higher stability,
3) Original imported rotary motor. Fast turning speed, steady turning brake.
4) The original imported hydraulic system, using double pump confluence technology, fast transfer speed.
5) Wheel deceleration wet front and rear axle, four-layer winding tubing, Doosan with the same standard buffer cylinder.
6) Can provide customized production to meet special construction and bidding needs.
Product Parameters
| Item | unit | specification | |
| machine weight | kg | 6600 | |
| bucket capacity | m3 | 0.3 | |
overall size | total length | mm | 6380 |
| total width | mm | 2150 | |
| ()total height(top of cabin ) | mm | 2827 | |
| tail rotation radious | mm | 2084 | |
| wheelbase | mm | 2400 | |
| min clearance ground | mm | 217 | |
specification | rated power | kw/rpm | 55/2500 |
| Maximum torque | N.m/rpm | 269/1610 | |
hydraulic pump | gear pump | Shimadzu | |
| The forerunner of pump | Mpa | 3.5 | |
| Pressure of work | MPa | 20 | |
| rated flow | L/min | 135 | |
| hydraulic oil tank | L | 127.9 | |
| Fuel tank capacity | L | 149.03 | |
| Rotary speed | rpm | 12 | |
| work speed | km/h | 30 | |
| bucket digging force | kN | 46 | |
| Maximum traction | kN | 47 | |
| Climbing ability | % | 59% | |
| (*) Dozer blade(width*height) | mm | 2150/500 | |
Working range | boom length | mm | 3260 |
| arm length | mm | 1750 | |
| max digging distance | mm | 6230 | |
| max digging depth | mm | 3500 | |
| max digging height | mm | 6300 | |
| max dumping height | mm | 4750 | |
| The minimum radius of gyration | mm | 2084 | |
