Durable and Sturdy CNC Heavy Lathe High Precision Equipment Surface Grinding Machine

Product Description

Product Description
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
General Specification
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Machine Equipment
A full-supported double-V structure design is adopted to the workbench, equipped with Turcite-B and a manual scraper to ensure excellent smooth operation and grinding accuracy under load.
X-axis movement is hydraulic driven.
- The Y&Z axis is driven by AC servo motor and C5 ball screw.
Automatic central lubrication.
- Independent Hydraulic System,Avoid the impact of vibration on the machine.
- The flanged cartridge type spindle is supported by P4 super precision angular contact ball bearings.

- Magnetic separator with 120L tank for effective cooling and rinsing. (Optional)
- KENT electro magnetic chuck.
Power supply = DC 110 volt, Single-phases, 50 Hz /60 Hz.
- KENT Y&Z axis digimatic gage.(Optional)

Equipped with automatic grinding wheel compensation function (the grinding wheel dresser uses an adjustable hydraulic system at the front and rear, and is driven by a stepper motor for the upper and lower wheels)
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Standard Equipment
Consisting of:

Granding Wheel Flange	Flange Removal Tool	Balance Table
Balance Rod	Grinding Wheel (Φ355*38*Φ127)	Tool Set
Machine to Adjust Sizing Block	Complete Document	Acceptance report According to DIN 8632

(Please note that standard accessories may vary depending on the specific model selected.)
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Product Parameters

Granding Range	mm	1500*600
Cross Travel	mm	660
Longitudinal Travel	mm	1600
Size of Electro-Permanent Chuck	mm	1500*600
Distance Table to Spindle Center	mm	600
Table Lode incl. Magnetic Chuck	kg	1300
Longitudinal Table Speed	m/min	7~28
Infeed Cross Axis (50Hz / 60Hz)	mm/min	1200/1500
Infeed Vertical Axis (50Hz / 60Hz)	mm/min	300/300
Grinding Wheel Dimensions	mm	Φ355*50*Φ127
Grinding Spindle Drive	hp(kW)	10(7.5)
Variable Speed of Grinding Spindle Motor	rpm	1500/1800
Machine Weight	kg	6250
Floor Space	mm	5810*2445

-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
