Basic Info.
Interior Material
Enameled Stainless Steel
Collector Components
Copper Heat Pipe and Glass Vacuum Tube
Composition
Heat Pipe, Glass Vacuum Tube, Enamel Wate Tank
Certification
ISO9001, CCC
Solar Heat Cllection Area
2.11 Square Meter
Enamel Water Tank
160L Capacity
Vacuum Tube
Pueple Gold Coating, Ø58*1800mmm
Quantity of Pipe
16 Pieces
Electric Heating
Power 2000W
Controller
with Controller
Transport Package
Carton /Wooden Packing
Product Description
| Capacity | 120L | 130L | 140L | 150L | 160L |
| Pipe Distance | 75mm | 75mm | 75mm | 75mm | 75mm |
| Vacuum Tube Specification | "purple gold" coating ,058mm×1800mm ,built-in metal heat pipe. |
| Bracket | Bracket galvanized spray bracket / bracket tilted 45° |
| Quantity | 12 pcs | 13 pcs | 14 pcs | 15 pcs | 16 pcs |
| Lighting Area | 1.59m2 | 1.73m² | 1.87m² | 2.00m² | 2.11m² |
| Total Capacity | 120L | 130L | 140L | 150L | 160L |
| Net Weight | 70.4kg | 74.5kg | 78.6kg | 82.9kg | 86.8kg |
| Electric Heating (optional) | Electric auxiliary heating power 2000W |
| Heat Pipe Type | Copper Heat Pipe |
| Controller | XK-3J or XK-5J |
TECHNICAL FEATURES
CONTROLLER TYPE
FAQ
Q1: Is your water tank stainless steel tank or enamel tank? A1: We are chinese national high-techology enterprise and one of leading enterprise of enamel water tank in china with 15-year enamel water tank production experience and over 30 technology patents. All our water heaters are adopted enamel tank. we do not produce stainless steel water tank.
Q2: Do your water heater uses glass heat pipe or metal heat pipe?
A2: We use copper heat pipe.The technology is the built-in heat transfer fin + copper tube heat conduction which made higher heat transfer efficiency.
Q3: What is the advantage of your copper heat pipe solar water heater system?
A3:(1) every solar tube works independently to avoid the failure of the entire water heater if one tube breaks.
(2) longer service life and pressure system
Q4: How long have you produced solar water heater and solar vacuum tube?
A4: 15-year production experiences for solar water heater,
10-year production experiences for solar vacuum tubes .
Q5: ODM and OEM available?
A5: we have established long-term OEM and ODM partnerships with over 40 domestic and international clients.
