Low Power-Consumption PE Stretch Film Recycling Pelletizer Machine

Product Description

Product Description
1.1 This machine is applicable to HDPE, LLDPE, LDPE, PAL waste films:edge film waste, air bubble film, pe stretch film recycling
1.2. Filter without screen and pelletize with rotary blade.
1.3 Production process: low-temperature type. (The screw does not need to be heated, and the first area of the pelleting head is heated by 1kw)
1.4 Water free and smokeless environment-friendly granulator Bubble film waste recycling granulator
Advantages:
Low power consumption, around 8-10kw per hour, no need water, no smoke, no smell,
Easy operation by one worker or during other jobs.
Product Parameters

model	70 /90
capacity	20-50KG/H
power	3Phase/380V/50HZ (customized available)
Hopper	size:300mm*300mm
Gear	Model:146#
	Hardness teeth
Screw	Extruder diamter:75mm L/D:1::9
	Material:38CR; Original Zhoushan
	Drive Motor:15KW 4grade
Cutter	Power: 0.75kw, Inverter: 0.75kw
Electricity	CHNT
Control system	Die heater:1zone; 1kw
Heater	cooling 1.1kw
cooling	Fan power 0.75kw

Detailed Photos
Packaging & Shipping
1.Packaging: wooden pallet or film wrapped (Fumigation wooden case usually)
2.Delivery time: 5-35/55 days after receiving deposit, depends on order and machine condition.
3.Exporting seaport: Ningbo port ; Shanghai port
4.Payment: we appreciate T/T 30% deposit, 70% balance paid before dispatching; Western Union;L/C acceptable if your goverment policy required
5.Trade terms: ExW,FOB,CFR,CIF,Door to Door, DDU, DDP,
FAQ
1.Where is your factory Located
Our Factory Located in Ruian City ,Zhejiang Province ,China .
It is about 30minutes by air from Shanghai, around 5hours by train from Shanghai
2.What machines range we make & supply?
Our factory focus on manufacturing extrusion lines, complete bag production line, etc; OEM, ODM, with support of strong R&D team, we also help customer get best solutions for special equipments and plastic machinery;
3.How can we get satisfied machine in hand?
We will make test once machine in ready, to check every parts working condition and electrocircuit; will record relative photo and video for installation in your place.
3. What should we charge if we need engineer service in our country?
You should charge for the cost of our engineer's visa, air tickets, hotel, food, and also their salary (negotiable)
4. How long is your machine's warranty period?
All our machine have two years guarantee, starting from finished installation. we still keep service for whole life.
5. How could we do if the parts broken within warranty?
We would send the free replacement spare parts during the warranty date.
