High-Precision Compact Wood Cutting CNC Machine with Water Cooling

Product Description

Product Parameters

Woking area	600*900*200mm or 600*900*500mm
Table style	Aluminum T-slot table with PVC
Table surface	Welded steel tube,cast iron vertical shafts and steel gantry
Spindle	3.0KW water cooling spindle
Spindle rotating speed	0-24000rpm
Collect size	ER20
Guide rail	Taiwan Hiwin linear square guide rail
Driving method	X,Y axis by helicia gear rack,Z axis by TBI ball screw
Motors and drivers	Stepper motor 450B and leadshine drivers MA860H
Control system	NCstudio control system
Invert	Fuling invert
Max.working speed	12m/min
Instruction formate	G code*.u00*.mmg*.plt
Woking voltage	AC220V/AC380V,single phase/3 phsae,50-60Hz
Standard software	Artcam 2010
Compatible software	Type3
Control Cabinet	Independent
Other	Tool sensor;Oiling system;Water pump;Tool Box,English manuals etc.
Optional parts	1)4.5kw water cooling spindle; 2)Rotary axis(80mm//100mm/150mm) diameter; 3)Mach3/DSP control system; 4)Dust collector; 5)Vacuum table with 5.5kw vacuum pump.

This machine can be tailored precisely to meet your unique specifications and requirements, ensuring it aligns perfectly with your needs.
Product Description
The Wayne CNC Router Machine, by Liaocheng Wayne New Materials Co., Ltd., is a state-of-the-art intelligent cutting and milling apparatus, meticulously engineered to address diverse and intricate processing demands. This highly adaptable machine excels in routing, drilling, cutting, sawing, slotting, and more. It features a sophisticated carousel tool magazine, strategically positioned either beside the spindle or on the machine's side, enabling seamless automatic tool changes. With this advanced functionality, the CNC router effortlessly executes complex operations in a single run, mastering tasks such as cutting, engraving, drilling, routing, grooving, and pocketing across various materials including wood, MDF, acrylic, PVC, plastic, foam, and beyond.
For enterprises demanding high production volumes, the Wayne CNC Router Machine stands as the premier choice. In stark contrast to the conventional manual tool change methods, this wood CNC machine boasts an autonomous tool magazine armed with a variety of tool bits. Through sophisticated computer program control, it seamlessly swaps the necessary tools without halting the workflow, ensuring unparalleled efficiency and precision during processing.
1. Wood Processing: Expertly handles the processing of a wide array of furniture including doors, windows, cabinets, and screens. 2. Advertisement: Effortlessly engraves and cuts various labels and number plates with precision.
3. Art Crafts: Skillfully engraves characters in any language and intricate graphics on gifts and souvenirs, adding a personalized touch.
Main Feature
1. Z-axis feeding height of 200mm, providing ample vertical clearance.
2. Robust square tube welded steel frame structure with 8mm thickness, ensuring durability and stability.
3. Versatile table options: Choose between an Aluminum T-slot table or a Vacuum table complemented by a powerful 5.5KW vacuum pump.
4. Precision-driven: X-axis rack and pinion drive, Y-axis dual rack and pinion drive, and Z-axis 2510 ball screw for superior accuracy.
5. X, Y, Z axes equipped with high-quality Taiwan square rails PMI for smooth and reliable motion.
6. Powerful drive system: 450B stepper motor and MA860H Leadshine driver or optional servo motor and driver for enhanced performance.
7. High-performance 3.0KW water cooling spindle and 3.7KW Fuling inverter, with additional spindle options available.
8. Advanced control system: Nc-Studio-5.4.49, with DSP or Mach 3 available as optional upgrades.
Options
1) 4.5KW water cooling spindle for increased power and efficiency.
2) Rotary axis options (80mm, 100mm, 150mm diameter) for versatile application.
3) Mach3/DSP control system for enhanced user control and adaptability.
4) Dust collector for maintaining a clean and efficient workspace.
5) Vacuum table with a robust 5.5KW vacuum pump for secure material handling and processing.
Detailed Photos
Packaging & Shipping
Company Profile
Liaocheng Wayne New Materials Co., Ltd. is a renowned leader in the world of CNC Routers and Laser Engraving & Cutting Machines. Strategically located in Liaocheng City, Shandong, we specialize in a diverse range of cutting-edge products: Large-Scale ATC Woodworking Router Machines, 5-Axis CNC Router Machines, CNC Advertising Router Machines, CNC Marble Engraving Machines, CNC Plasma Cutting Machines, CNC Metal Mold Machines, CNC Lathe Machines, Swiss-Type Lathe Machines, Fiber Laser Cutting Machines, CO2 Laser Cutting & Engraving Machines, Laser Marking Machines, Laser Welding Machines, and more. Leveraging high-tech innovations and superior quality, we aim to build the global brand 'Wayne'. Our exceptional machines are exported to over 100 countries and regions including the United States, Germany, Indonesia, Canada, Australia, Russia, Southeast Asia, and beyond.
Our primary mission is to deliver unparalleled service to our customers. Whether it's stock or custom configurations, we excel in both. We source components from world-class suppliers and innovators in machine control to ensure top-notch performance. Our machines find applications across various industries and crafts, including woodwork, metal and stone work, aluminum fabrication, boat building, shop fitting, mold making, and more. Driven by a dedicated after-sales service department, a skilled sales team, and rigorous quality assurance procedures, we guarantee you can purchase with confidence. We warmly welcome customers and potential business associates from around the globe to collaborate for mutual benefit. 'Best Service, Best Quality, Best Price'-Wayne is your ultimate choice. We eagerly look forward to collaborating with you to create greater value. Awaiting your inquiries-let's connect and discuss your needs. I am here, ready to assist.
FAQ
1. Is it all right to make customer's own brand name?
A: yes. we are available with OEM
2. Are you a manufactuer or trading company?
A:We are the manufacturer with Laser machine and CNC lathe machine
3. Can you do the design for us?
A: yes. if you want a different control system design or higher column , we are available.
4 . What is your terms of delivery?
A: FOB Qingdao.
5. What's your payment term?
A: T/T OR L/C at sight.
