12 Cavity 30mm Cold Runner Precision Plastic Injection Mould for Tear off Cap of Medical Bottle

Product Description

Mould type	ODM plastic injection molding
Mould material	45#, 50#, P20, 738, 738H, 718, 718H, NAK80, 2316, 2316A, S136 etc
Product material	PS, ABS, PP, PVC, PMMA, PBT, PC, POM, PA66, PA6, PBT+GF, PC/ABS, PEEK, HDPE, TPU, PET, PPO,...etc.
Other materials:	Rubber, Slilconce rubber, LSR,Aluminum, Zinc,Copper...Metal...etc.
Mould precision	±0.005mm.
Mould machine center	Milling, grinding, CNC, EDM, wire cutting, carving, EDM, lathes etc.
Mould Base type	LKM, FUTA, HASCO, DME, TSMP, Or as per customer's requirement.
Steel hardness	20-60HRC
Surface Finish:	Texture(MT standard), High gloss polishing
Cavity/Core Steel:	P20, 2311, H13, 2344, Starvax 420, 236, AdC3, S136, 2312, 2379, 2316, 2083, Nak80, 2767 ...etc.
Hot/ Cold Runner	HUSKY, INCOE, YDDO, HASCO, DME, MoldMaster, Masterflow, Mastip, Taiwan made brand...etc.
R&D	1. Drawing design and making for products and mold;
	2. Mold drawing revising;
	3. Production time and quality control in each machining process.
Port	SHEN ZHEN
Manufacture type	Injection mold, surface treatment available
Standard:	ISO9001:2008; RoSH and SGS standard
To be discussed	In-Mold Decoration, Injection Mould, Plastic Mold, Overmould, 2K Mould, Die-Casting Mould, Thermoset Mold, Stack Mold, Interchangeable Mold,Collapsible Core Mold, Die Sets, Compression Mold, Cold Runner System LSR Mold,...etc.
Mould Life:	5,000 to 1,000,000 Shots. (According to your working environment.)
Design & Program Softwares:	CAD, CAM, CAE, Pro-E, UG, Soild works, Moldflow, CATIA....etc.
Equipments:	High speed CNC, Standard CNC, EDM, Wire Cutting, WEDM, Grinder, Plastic Injection Molding Machine for trial out mold from 50-3000T available.

Plastic injection mold This is 24mm PE tear off cap for medicine bottle. The cap demould system by slider and stripper plate and do in 12cavity. The core&cavity use German2344, mould base standard 718H

The mould can be running on 160T injection machine, do in cold runner and automatic demould drop cap can save worker cost and reduce cycle time.

Mould processing by complete steps from design to purchase steel material, first step maching, inspection, precision machining, assemble and test, check samples. The mould steel do heat treatment keep strength and work life.

Operational specifications, regular cleaning and maintenance can make the mold life more longer. When we make mould also provide extra some quick-wear spare parts for customer, such as O ring, ejector pin, water connector, spring and so on which easy to replace basic wearing parts. Normally after sale is one year after mould delivery, DXTL provide technical support all time.

Processing:

After the drawing is confirmed by the customer, the mold will be processed in a perfect and careful way. Every part will be processed and processed, and the size will be checked to see if it is correct. Every link will be monitored effectively to ensure that no error will occur in the process. After the mold assembly is completed, the mold will be tested to verify whether the mold action is OK and whether the product is OK

For mould DXTL provide technical support all time and normally after-sale service 1year which if have any spare parts problem we will repair or change by free but expect damage by human.
DXTL has its own plastic industry technology research and development studio. In the past twenty years or so, DXTL has obtained multiple patent certificates for mold design, mold structure manufacturing, plastic component invention, plastic component function improvement, and new inventions in the plastic field.
The R&D team of DXTL has so far developed solutions such as gas assisted plastic molding technology, water injection plastic molding technology, high gloss injection molding, stacking molding, multi-color injection molding, foam injection molding, etc. All of these are the latest plastic industry technologies in Europe. Therefore, DXTL ranks among the top mold manufacturers in China and has gained unique advantages in the molding market.
Thanks to our R&D team's long-term research experience in plastic molds, DXTL molds can become the most professional plastic molding technology and mold supplier in China. With the IATF16949 management system combined with years of experience in mold manufacturing, DXTL is very strict on important issues and key points in mold manufacturing. DXTL has a rigorous mold manufacturing process, renowned for hundreds of special mold structures, and provides customers with advanced injection molding technology solutions. And we have established good relationships with European mold manufacturers and provided internationally renowned injection molding plastic consulting services.
