Reliable Performance Grinding Machine with Permanent Magnet Chuck and Syntec CNC

Product Description

250/2550CNC Surface Grinding MachineIntroducing the Three Axies 250CNC Multifunction Grinding Machine Tool, a marvel of precision engineering designed to elevate your machining capabilities.
We adhere to a robust policy of perpetual enhancement for all our products. Thus, we retain the liberty to amend specifications, mechanics, or designs at any given time, without prior notice or obligation.

	parameter	unit	CNC-250	CNC-2550
general picture	Table size (x*y)	mm	200×500	250*500
	X axis travel	mm	580	580
	Y axis travel	mm	230	280
	Max center of wheel to table	mm	380	380
	Maximum load	kg	200	200
Table	Table T cell specification	mm×N	14×1	14×1
	Table speed	m/min	0-25	0-25
Y axis	Minimum feed	mm	0.001	0.001
	Single feed		0.1~10	0.1~10
	Fast moving speed	mm/min	0~1200	0~1200
Z axis	Minimum feed	mm	0.001/0.01	0.001/0.01
	Fast moving speed	mm/min	0~800	0~800
grinding	grinding wheel size max	mm	Φ200×Φ31.75×19
	grinding wheel speed	R.P.M	0~3600	0~3600
motor	spindle motor	HXP	2×2	2×2
	the Z axis motor	W	750	750
	the Y axis motor	W	750	750
	the X axis motor	W	1500	1500
	cooling motor	W	90	90
Size	height of machine	mm	2000	2000
	floor space	mm	2000×1350	2000×1450
	weight(about)	kg	1450	1550

Cheng Yu Machinery Technology Co., Ltd., proudly established in Dongguan City, Guangdong Province, is built upon a heritage of 30 years' profound expertise in grinding machine manufacturing from Taiwan, driven by a dedicated and highly-skilled team of technical personnel. With the brisk advancements in CNC machine tools, the industry is steering towards high-speed, high-precision, composite, and intelligent solutions. Embracing openness, parallel drives, connectivity, and eco-friendliness perfectly encapsulates the future trajectory of CNC machine tools. Dongguan Chengyu Machinery Technology Co., Ltd. specializes in crafting and processing a diverse range of machine tools and accessories. With our guiding principles of 'technology, innovation, reliability,' combined with a commitment to 'meticulously' stringent quality, we are dedicated to delivering superior products and exceptional service to our valued clients. From understanding the client's process needs to the final product development, we emphasize high precision, complete automation, and unrivaled quality, supported by state-of-the-art equipment and sophisticated technology, ensuring our superior standing in the CNC industry. In a strategic response to market demands, Chengyu Machinery excels in the innovative design and manufacture of high-precision CNC surface grinding machines, CNC forming machines, four-axis punch grinders, vertical slider grinders, and gantry rail grinders. Additionally, we advance in creating industrial robots, automated production lines, and integrated applications. Below is a concise overview of our cutting-edge CNC grinding machine series: I. HS Series: Models 618 / 250 / 3060 / 4080 / 40100 (Available in both servo and hydraulic types) offer unmatched versatility. Processing Capacity: Master the art of surface grinding and grooving with impeccable precision. Featuring a patented hydraulic control system (hydraulic type) for enhanced operational efficiency. Function: Equipped with advanced grinding programs capable of flat surface and groove cutting. Feed Mode: Selectable front/back/left/right feed options, with each grinding program retaining its memory feed mode. Experience convenience with automatic shutdown features for grinding wheel overload. II. (Available in both servo and hydraulic types) Processing Capacity: Engage in surface grinding, grooving, and combined scheduling for versatile applications. Featuring a patented hydraulic control system (hydraulic type) for streamlined operations. Function: Empowered with various grinding programs tailored for surface grinding, groove cutting, sole grinding, side grinding, and unequal distance/depth displacement grinding. Grinding Wheel Dressing: Features bottom plane dressing with set rough/fine grinding dressing time and amount, enabling automatic dressing and compensation within the grinding cycle. Feed Mode: Selectable front/back/left/right feed modes, with each grinding program maintaining its memory feed mode. Efficiently perform equidistant grooving or non-equidistant unequal tasks with precision. 3. Four-axis CNC grinding machines are meticulously designed, available in both horizontal and vertical types. Processing Types: Achieve arbitrary equal division and skipping tooth processing with ease. Seamlessly enter waist circle dimensions with AB size inputs. For triangle fillets, simply input the inscribed circle size B and fillet size R. For quadrilateral fillets, conveniently enter side length A, side length B, and fillet size R. For eccentric circles, input eccentricity alongside starting and ending diameters for precise results. Circle: Seamlessly input the starting and ending diameters to achieve precision and excellence in every circular project. Arc: Effortlessly define the arc size and rotation angle, allowing for creative and precise shaping in your work. Step Difference and Rotation Profile: Easily manage step differences and rotation profiles to ensure consistent quality and innovative design solutions. Processing Schedule: Save your processing schedule as a convenient processing file, ensuring swift and effortless retrieval for your next project endeavor.
