Automatic Facial Tissue Production Line Napkin V Fold Paper Making Machine

Product Description

CBM-FT-A-D Automatic Facial Tissue Production Line napkin V fold paper making machine
No.1 CBM-FT-20A full-automatic box-drawing facial tissue machine CBM-FT-A-D Facial tissue production line combined embossing, folding, counting, match with
high-speed paper cutting machine, conveying, automatic box, automatic seal box. It much save
manpower. This machine adopt PLC computer programming technology, frequency control, servo
feeding control, match with touch type screen man-machine interface operating system. The whole
machine adopts synchronous belt drive. Folding machine can match with automatic tension control
system, to suitable various kind of raw material,
greatly improve quality and efficiency. This production enjoy with easy operation flow, high production
efficiency, perfect product , moreover, it can match with automatic multi boxes wrapping packaging machine.
Descriptions: This model is designed to produce `link type' box-drawing facial tissue, that's mean, each sheet link
together, draw the top tissue , the head of next sheet will come out the box. And this machine can
produce either embossed or without embossed for customers' selection. It has a feature of tight
structure, easy operation, stable operation and elaborate designed. We can make the machine with
1line, 2lines, 3 lines ,4 lines, 5 lines and 6 lines.Production Lines generally use 6 lines and 8 lines.
This machine can equip with single color printing or double color printing unit. Technical parameter: Main technical parameter:

Final product size (mm)	200×200±2mm 100×200±2mm
Diameter of jumbo roll(mm)	¢1000-1200(Other specification, please specify)
Width of jumbo roll(mm)	1200mm
Core inner dia. of jumbo roll	76.2mm(Other specification, please specify)
Production speed	0~100 meter/min.
Power	3 phase, 380V/50HZ,
Controller	Frequency control
Cutting system	point cut by pneumatic type
Vacuum system	18.5KW Roots vacuum system
Host power	18.5 KW
Overall dimension	6000×2600×1920 mm
Machine weight	3.0T

No.2 CBM-FT -281 Convolute facial tissue cutting machine
High speed Convolute facial tissue cutting machine is an important component equipment of
Box-drawing facial tissue production line , which can greatly improve the level of automation and
production efficiency of the production line. The machine is strong, beautifully designed, cut Paper
precise movements, rolls flat section, and smooth.
Configuration as following:
1.With automatic sharpening function
2.Automatic kick waste function
3.Lateral cutting structure, blade higher utilization 4.Sharpening wheels can be automatically adjusted according to the degree of wear of the blade sharpening;
5.Overall size:2000*1700*1700mm
6.Cutting length:90-250 adjustable
7.Speed :100-130mm 140 cuts/min, 200-230mm 80 cuts/min
8.Power of main motor:2.2KW
9. Power of cutter motor:2.2 KW
No.3 CBM-FT-268 Full-automatic tissue carton packing machine
Main performances and features:
1.Adopts automatic material conveying, box opening, feeding, batch No. printing, glue spraying,
box sealing, with compact reasonable structure, easy for operation.
2.Adopts servo motor / sept motor, PLC touch screen programmer system, human-machine display
easy for operate, and design with higher mechanization and hommization.
3.Adopts full automatic arrange converying structure, easy connect with automatic line producing,
make reduce the labor cost.
4.Adopts automatic photocell eye tracking system for empty box, and save the pack material xost.
5.With widely packing range, easy adjustable for different specification requirements.
6.Change the different size just adjust the machine no need change the mould.
7.With automatic stopping for the miss box feeding, also has the overload protection.
CBM-FT-268 Full-automatic high-speed tissue carton packaging machine

Item/model	CBM-FT-268
Paper quality of carton	300-400g/m3
Maximum packing specification	L240mm×W120mm×H90mm
Packing speed	30-40(boxes/minute)
Hot melt machine power	2.32KW
Motor power	2.65KW
Total power	5KW
Power supply type	220V 50Hz
Machine noise	≤80dB
Air supply	0.5-0.8 Mpa
Air consumption	120-160L/min
