Factory Direct Sale Anticorrosion PVDF Np Standardized Chemical Pump

Product Description

Product Description NP series chemical pump Applications Type NP standardized chemical pumps are the solution of choice whenever it comes to pumping acids, alkali or chemically contaminated fluids in the presence or absence of solids. Typical applications include the chemical and metal finishing industries, steel and stainless steel pickling lines, evaporation and regeneration units, flue gas scrubbing downstream of waste incinerators as well as exhaust air cleaning and scrubber effluent treatment. Construction Horizontal centrifugal pump with volute casing and single entry, single-stage radial impeller, nominal pressure PN 10. Casing and fitting dimensions to EN 22858/ISO 2858, complemented by size 40-25-160 and 250-200-400 pumps. Performance data Pump capacity up to 1200 m3 /h Total differential head up to 100 m Diameter of discharge nozzle DN 25 up to DN 250 Motor rating up to 200 kW Shaft seal Single or double mechanical seal Flange connection Standard design to DIN 2501 PN 16 ,ANSI B16.5 class 150, JIS B2210 class 10K.

Item	value
Warranty	1 year
Customized support	OEM, ODM, OBM
Brand Name	PIONEER
Model Number	NP125-100-200
Place of Origin	Shanghai
Application	Drinking water treatment, Food and Beverage Industry, Industrial Boilers, Industrial Utilities, Raw Water Intake, Wastewater Transport and Flood Control, wastewater treatment, Water Treatment Solutions
Horsepower	55hp
Power Source	Electric
Pressure	up to 10 bar
Structure	Single-stage Pump
Outlet Size	100
Voltage	380v/440V
Power	55kw
motor	IP55
Structure	Horizontal chemical centrifugal pump
Material	PVDF/PP/PE
Certification	ISO2858
Standard or Nonstandard	Standanrd
Color	Customer Specifications
Feature	Corrosion Resistant
Impeller	Closed or Semi-open Impeller
Weight	320kg
Shaft	Single or double mechanical seal

Detailed Photos
Certifications
Packaging & Shipping Plywood Case for safety
Company Profile
FAQ 1. who are we?We are based in Henan, China, start from 2019,sell to Domestic Market(20.00%),Southeast Asia(20.00%),Eastern Asia(10.00%),Mid East(10.00%),South America(10.00%),Northern Europe(10.00%),Africa(5.00%),South Asia(5.00%),North America(5.00%),Central America(5.00%). There are total about 5-10 people in our office.2. how can we guarantee quality?Always a pre-production sample before mass production;Always final Inspection before shipment;3.what can you buy from us?centrifugal pump,industrial valve,PTFE lined pipe,chemical pump,Plastic pipe4. why should you buy from us not from other suppliers?Luoyang Pioneer Anticorrosion is specialized in the manufacturing of international quality anti corrosion pumps,valves,pipes and fittings. The products are widely used for scrubbing, steel pickling, electroplating, paints, dye stuffs, chlor alkali,5. what services can we provide?Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,DDP,DDU,DAF;Accepted Payment Currency:USD,EUR,CNY;Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash;Language Spoken:English,Chinese,Russian
