Haixiong/Highsun Plastic Injection Molding Machine
| US$10,000.00-60,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
HXM530
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Energy Saving
Servo Energy Saving
After Sales Service
Engineers Avaiable to Service Machine
Voltage
According to Countries
Showroom Locate
Malaysia,Russia,Turkey,Uzberkistan
Condition
100% New
Machine Weight
19.7 Ton
Transport Package
Standard Packing
Specification
8.1*2.14*2.5
Trademark
HIGHSUN
Origin
China
HS Code
847710
Production Capacity
7000sets/Year
Product Description
| MODEL: HXM530-I | ||||
| TECHNICAL PARAMETER TABLE | A | B | ||
| INJECTION UNIT | SCREW DIAMETER | mm | 75 | 80 |
| SCREW L/D RATIO | L/D | 21.3 | 20 | |
| INJECTION CAPACITY IN THEORY | cm3 | 1634 | 1860 | |
| INJECTION WEIGHT(PS) | g | 1495 | 1701 | |
| oz | 52.7 | 60.0 | ||
| INJECTION PRESSURE | MPa | 191 | 168 | |
| INJECTION RATE | g/s | 382 | 435 | |
| PLASTICIZING CAPACITY | g/s | 52 | 57 | |
| SCREW SPEED | rpm | 150 | ||
| CLAMPING UNIT | CLAMPING FORCE | KN | 5300 | |
| MOVING MOULD-PLATE STROKE | mm | 830 | ||
| MAX. MOULD HEIGHT | mm | 830 | ||
| MIN. MOULD HEIGHT | mm | 330 | ||
| SPACE BWTWEEN TIE-BARS (W×H) | mm | 860x810 | ||
| HYDRAULIC EJECTOR FORCE | mm | 181 | ||
| HYDRAULIC EJECTOR STROKE | KN | 230 | ||
| EJECTOR NUMBER | n | 17 | ||
| OTHERS | PUMP PRESSURE | MPa | 16 | |
| MOTOR /DRIVING POWER | KW | 45/30x2 | ||
| HEATING CAPACITY | KW | 26.45 | ||
| MACHINE DIMENSION (L×W×H) | m | 8.1x2.14x2.5 | ||
| MACHINE WEIGHT | t | 19.7 | ||
| OIL TANK CAPACITY | L | 969 | ||
