Basic Info.
Structure
Vertical Drilling Machine
Controlling Mode
Artificial
Automatic Grade
Automatic
Certification
CE, ISO 9001
Dimension(L*W*H)
825X490X290mm
Drilling Speed
16 Classes
Max. Drilling Dia. (mm)
16
Range of Spindle Speed(r.p.m)
180 - 3320 r.p.m
Product Description
Product Description
Discover the HY5216B-II 450W Table Drill Press by Shanghai Hystrong Industrial Co., perfect for hobby/home use with a 290x290mm table size.
Specification
HY5216B-II Mini Bench Drilling Press Machine Introducing the HY5216B-II Mini Bench Drilling Press Machine from Shanghai Hystrong Industrial Co., Ltd. This manual drilling press is perfect for those seeking an economic yet high-quality solution. With its compact size and elegant design, this new machine offers exceptional performance and durability.
Main Features:
Excellent performance
Powerful motor
OEM accepted
Small bench type
Experience the precision and reliability of this Mini Bench Drilling Press Machine, designed to meet your drilling needs with efficiency and ease. Don't compromise on quality - choose the HY5216B-II for your workshop today!
Max. Drilling diameter
| 16mm
|
Motor power
| 375/450/550W
|
Chuck capacity
| 3-16mm
|
Spindle travel
| 85mm
|
Class of speed
| 16
|
Speed 50HZ/60HZ
| 18~2770/220~3320rpm
|
Spindle taper
| MT2
|
Swing
| 360mm
|
Table size
| 290x290mm
|
Base size
| 420x270mm
|
Column Diameter
| 72mm
|
Height
| 1000mm
|
N.W./G.W.
| 55/57kg
|
Packing size
| 825x490x290mm
|
Package Details
Company Profile
Welcome to Shanghai Hystrong Industrial Co., Ltd.
With over twenty years of experience in manufacturing and exporting high-quality industrial tools, we have built a strong reputation for excellence and top-notch after-sales service worldwide.
Our commitment to quality is unwavering. We meticulously select raw materials and utilize advanced manufacturing equipment to ensure the superior quality of our products.
We understand the importance of delivering consistent high-quality tools to support your operations. With our extensive knowledge and expertise, we can customize tools to meet even the most demanding requirements.
Certifications
FAQ
Product Description
Welcome to Shanghai Hystrong Industrial Co., Ltd. Product: Industrial Machines 1. Payment Terms: Our payment term is 30% T/T in advance, 70% T/T before shipment. It is negotiable.
2. Delivery Time: Usually, one machine takes 20-40 days. If we have in stock, we can arrange shipment as soon as we receive the payment.
3. Factory Location: Our factory is located in Yancheng, Jiangsu Province. We sincerely welcome you to come to our factory.
4. CE Certification: Yes, we have CE certification, ensuring machine quality.
5. OEM Orders: We accept OEM orders with your logo printed on the machine and packaging designed according to your specifications.
