API Series Cjy6 Cyj10 Cjy 12 Double -Horsehead Oil Well Pumping Unit

Product Description

API series CJY6 CYJ10 CJY 12 Double -Horsehead oil well Pumping Unit
Double -Horsehead Pumping unit
Product Description API series CJY6 CYJ10 CJY 12 Double -Horsehead oil well Pumping Unit
Product Features:
Double horsehead pumping unit is a kind of energy-saving product with long stroke and low stroke frequency. It is suitable for the recovery of moderate and low viscosity oil and high water-cut crude oil. The product accords with Chinese petroleum industry standard GB/T29021-2012 and other related standards.
API series CJY6 CYJ10 CJY 12 Double -Horsehead oil well Pumping Unit
Performance and advantage
1 It adopts reducing arc-shaped back walking beam and flexible connection between walking beam and equalizer. Advantages of conventional pumping unit are retained.
2 Long stroke length, small dynamic load, little torque fluctuation, high efficiency, low energy consumption, smooth work and easy to start.
3 The stroke length is increased by 70% around, energy consumption reduced by 20~30% and power reduced by 50%, compared with conventional pumping unit of the same model.
Product Parameters
Product Specification

Model	Rated Polished Rod Capacity (lbs)	Stroke (in)	Rated Torque of reducer (lbs.in)
C-912D-470-240	47,000	240,211,181	912,000
C-912D-427-216	42,700	216,185,155	912,000
C-912D-427-192	42,700	192,165,138	912,000
C-912D-305-192	30,500	192,165,138	912,000
C-912D-365-168	36,500	168,144,120	912,000
C-912D-305-168	30,500	168,144,120	912,000
C-912D-427-144	42,700	144,120,100	912,000
C-640D-305-192	30,500	192,165,138	640,000
C-640D-305-168	30,500	168,144,121	640,000
C-640D-365-144	36,500	144,120,100	640,000
C-640D-305-144	30,500	144,120,100	640,000
C-640D-256-144	25,600	144,120,100	640,000
C-640D-305-120	30,500	120,102,85	640,000
C-456D-305-168	30,500	168,144,121	57,000
C-456D-305-144	30,500	144,120,100	40,000
C-456D-256-144	25,600	144,120,100	57,000
C-456D-365-120	36,500	120,102,85	40,000
C-456D-305-120	30,500	120,102,85	25,000
C-456D-256-120	25,600	120,102,85	25,000
C-320D-256-144	25,600	144,120,100	320,000
C-320D-256-120	25,600	120,100,85	320,000
C-320D-213-120	21,300	120,100,85	320,000
C-320D-305-100	30,500	100,85,70	320,000
C-320D-256-100	25,600	100,85,70	320,000
C-320D-213-86	21,300	86,74,62	320,000
C-228D-213-120	21,300	120,100,85	228,000
C-228D-173-100	17,300	100,86,72	228,000
C-228D-246-86	24,600	86,74,61	228,000
C-228D-213-86	21,300	86,74,61	228,000
C-228D-200-74	20,000	74,64,54	228,000
C-228D-173-74	17,300	74,64,54	228,000
C-160D-173-86	17,300	86,74,62	160,000
C-160D-200-74	20,000	74,64,54	160,000
C-160D-173-74	17,300	74,64,54	160,000
C-160D-143-74	14,300	74,64,54	160,000
C-160D-173-64	17,300	64,54,44	160,000
C-114D-119-86	11,900	86,72,59	114,000
C-114D-143-74	14,300	74,62,51	114,000
C-114D-173-64	17,300	64,54,44	114,000
C-114D-143-64	14,300	64,52,40	114,000
C-114D-133-54	13,300	54,45,36	114,000
C-80D-119-64	11,900	64,53,42	80,000
C-80D-133-54	13,300	54,45,36	80,000
C-80D-119-54	11,900	54,45,36	80,000
C-80D-133-48	13,300	48,40,32	80,000
C-80D-109-48	10,900	48,37,25	80,000
C-57D-76-54	7,600	54,41,28	57,000
C-57D-109-48	10,900	48,37,25	57,000
C-57D-95-48	9,500	48,37,25	57,000
C-57D-89-42	8,900	42,33,23	57,000
C-57D-76-42	7,600	42,33,23	57,000
C-40D-76-48	7,600	48,37,25	40,000
C-40D-89-42	8,900	42,33,23	40,000
C-40D-76-42	7,600	42,33,23	40,000
C-40D-89-36	8,900	36,28,20	40,000
C-25D-67-36	6,700	36,28,20	25,000
C-25D-56-36	5,600	36,28,20	25,000
C-25D-53-30	5,300	30,20	25,000

API C Series Pump Jack Effect Diagram API C Series Pump Jack Drawing
