Plastic Recycling Machine Parts Continuous Screen Changer

Product Description

Our advantages
1, Senior technical engineer with more than 15 years of experience in the polymer filtration fields
2, Fully equipped with all needed fabricating machinery,guattantee the quality and the date of delivery of the products.
3,Customized design is welcome
4,Quick delivery time
5,OEM service is provided
6,Reliable and trustworthy service

Product Description

Plastic recycling mahcine parts continuous screen changer
This GM-DP-L series Double piston large filter area continuous screen changer for plastic extrusion machine is consist of
The main body of the screen changer
Hydraulic unit
Electrical controlling pack(this part is optional choice by customers, the above picture shows two kind of controll system)
This GM-DP-L series Large filter area continuous screen changer for plastic extrusion machine is designed based on GM-DP-R series dual rods continuous screen changer , this kind of continuous screen changer enlarge the filtration area by instead the round breaker plates as the rods full of holes, and the filter screen is wrapped on the rods full of holes. And this kind of continuous screen changer now is widely used for the hot melt adhesive, high output plastic recycling machine.
So the filtration area of the GM-DP-L series screen changer is much more larger than the GM-DP-R series continuous screen changer, it meets the high yield device requirements.


After successful trials atJiangsu Province,an ABS recycling factory, we have installed two sets of this GM-DP-L series large filtration area continuous screen changer on the ABS recycling machine .Through the filtration process, The ABS flakes can be processed at a throughput rate of 1100kg/h. And during the screen change process, the strands do not interrupted . and there are no bubbles in the final granules That is to say, this kind of large capacity screen changer can meet the high output recycling extrusion machine and can realize the continuous production without interruption

Characteristics of GM-DP-L series large filtration area continuous screenc hanger for plastic extrusion machine
The filter screen is wrapped on each slide bearing bars full of small holes-the same function as the breaker plates
"Continuous type" means operation of screen change without machine halt or disruption of melt flow.
Equiped with air venting system
Fit for almost all kinds of polymers
It works well under the high pressure 400bar(40Mpa) not impact the high performance.
The filtration screen area covers from 400cm² to 2500cm², depending on the size, fit for output range from 100kg/h to 4800kg/h.
Product show
Benifits of this kind of double piston type continuous screen changer with large capacity for plastic extruder
Continuous operation
Leak-free mold of operation
Large filtration area meet the high output extrusion machine
Customized design adapters
venting groove discharge the gas mixed in the polymer melt
Simply controll by a easy operated control handle
Reasonable price and proved technology
Main application fields
Especial for the high yield device
Sheet (Foam/Strapping/Plastic cardboard)
Coating (Hot melt adhesive)
Pipe ( Corrugated/Gas Pipe) and profile
Compounding (Master batch/filler)
Wire and cable extrusion
Tubing (Medical/Industrial/Irrigation)
Fibers ( Monofilament/non-woven fabrics)
Pelletizing (strands and water-ring pelletizing)
Recycling of most polymers
Application cases show



The screen changer types and parameter

Type	Screen D&A		O verall dimension (mm)				Heating power (KW))	Output (kg/h)
	S creen diamension L*W (mm)	Filtration area (CM²)	L	W	H	L1
G M -DP-L-100	251x80	200x2	220	200	320	810	3.5/4.7	450-1200
G M -DP-L-120	314x100	314x2	250	220	360	970	5.0/7.2	800-1800
GM -DP-L-155	408x130	530x2	320	270	450	1100	8.2/11.1	1000-2600
G M -DP-L-175	471x180	846x2	370	310	480	1320	9.4/12.7	2300-4400
G M -DP-L-195	533x190	1012x2	400	380	550	1470	10.2/13.8	2900-6000
G M -DP-L-220	596x200	1192x2	440	410	590	1620	13/17.5	3900-10000
Remark: The output rates depend on the individual extrusion process parameters.
