RAM Milling Machine CNC Machine Is Optional

Product Description

Big accuracy milling machine with big ram travel ISO40
Product Parameters

Items	XQ6432	XQ6432A	XQ6432B	XQ6432C
Working area
Worktable size (L×W)	1270x320mm	1370x320mm	1270x320mm	1370x320mm
T slot (Width x No. x pitch)	14x3x80mm
Max. load of table	300kg
Table rotation	optional: ±45˚
Distance from horizontal spindle axis to table surface	65-465mm
Distance from vertical spindle nose to table surface	250-650mm
Travels
Worktable longitudinal travel (X)	720mm	820mm	900mm	1000mm
Worktable cross travel (Y)	300mm (If with DRO:280mm)		380mm (If with DRO:360mm)
Worktable vertical travel (Z)	400mm
Ram travel	460mm
Spindle
Horizontal spindle speed	12 steps; 35-1500rpm
Spindle taper(Horizontal)	7:24, ISO40
Motor power(Horizontal)	3kW
Universal milling head spindle speed	11 steps; 45-1660rpm
Spindle taper(Universal milling head)	7:24, ISO40
Universal milling head swivel angel	±360°
Motor power (Universal milling head)	3kW
Feed
Rapid feed (X/Y/Z)	1335/1335/1000mm/min
Feed range (X/Y)	30-830mm/min
Feed range (Z)	23-625mm/min
Others
Machine size (L×W×H)	1720x1680x1860mm	1820x1680x1860mm	1720x1680x1860mm	1820x1680x1860mm
Net weight	1850kg	1900kg	1900kg	1950kg

other models

Items	XL6436	XL6436C	XL6436CL
Working area
Worktable size (L×W)	1325x360mm	1325x360mm	1600x360mm
T slot (Width x No. x pitch)	18x3x80mm
Max. load of table	350kg
±45°table rotation	optional
Distance from horizontal spindle center to worktable surface	0-450mm
Distance from spindle nose to table surface	175-625mm
Travels
Worktable longitudinal travel (X)	750mm	1100mm	1300mm
Worktable cross travel (Y)	320mm
Worktable vertical travel (Z)	450mm
Ram travel	550mm
Spindle
Horizontal spindle speed	12 steps; 60-1800rpm
Spindle taper(Horizontal)	7:24, ISO50
Motor power(Horizontal)	5.5kW
Universal milling head spindle speed	12 steps; 60-1750rpm
Spindle taper(Universal milling head)	7:24, ISO50
Universal milling head swivel angel	±360°
Motor power (Universal milling head)	4kW
Feed
Rapid feed (X/Y/Z)	1200/800/600mm/min
Feed range (X)	30-750mm/min
Feed range (Y)	20-500mm/min
Feed range (Z)	15-375mm/min
Servo motor torque	15Nm
Others
Machine size (L×W×H)	1800x2100x2000mm	2245x2100x2000mm		2520x2100x2000mm
Net weight	2685kg	2750kg		2800kg

Detailed Photos
√ universal 360° swivel head can process any angle surface √ 27 speeds spindle, gearbox driven directly, wide speed range for powerful milling √ power driven sliding ram, very long travel in Y-axis
√ 500x2000 mm large work-table, long travel
√ double-supporting-column design, 1800kg heavy load capacity

√ table feeding is driven by 3 independent servo motors, high accuracy, low noise, can achieve 3-axis synchronous feeding
√ 3-axis ball screws for good precise
√ 3-axis E-handwheels on control panel, manual feeding is easy and precise √ scientific circult design for easy maintenance
Configuration
optional configuration
Certifications

Packaging & Shipping
Delivery time: generally 3 months production time after confirmation of order
Packing type: machine need to be dismantled to load into container, covered with damp-proof plastic film, then packed in thickened water-proof cover on steel pallet
