JIS H3100 C2200 C2801 H90 H62 Cuzn10 Cuzn38 Brass Alloy Plate Price Per Kg

Product Description

JIS H3100 C2200 C2801 H90 H62 CuZn10 CuZn40 Brass Alloy Plate price per kg
Copper bar is a kind of non-ferrous metal processing bar, with better processing performance, high conductivity.It is mainly divided into brass bars (copper-zinc alloy, cheaper) and copper bars (higher copper content)
Brass bars are rods made of an alloy of copper and zinc. They get their name from their yellow color.Copper content of 56%~68% of brass, its melting point of 934~967 degrees.The mechanical and wear resistance of brass are very good, can be used in the manufacture of precision instruments, ship parts, gun casings and so on. Different amounts of zinc can have different colors, such as red and yellow for zinc content of 18%-20%, and brown-yellow for zinc content of 20%-30%.In addition, brass sounds unique, so the eastern gongs, cymbals, bells, horns and other instruments, as well as western brass instruments are made of brass. Materials H59, h59-1, h59-2, h59-3, H60, h60-2, H62, H63, H65, H68, H70, H80, H90;C1100, C1020, C2680, C2800, C2600, C2801, C5191, C5210, C2200, C7521, C7541, C17200, C1070, C7701, qsn6.5-0.1, qsn8-0.3, qsn4-0.3, bzn18-18, bzn15-20, CuBe2 and many other materials.

1.	Item	Brass Plate/Copper Plate
2.	Standard	ASTM,AISI,EN,BS,JIS,ISO,GB
3.	Material	C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910, C10920,C10930,C11000,C11300,C11400,C11500,C11600,C12000, C12200,C12300,TU1,TU2,C12500,C14200,C14420,C14500, C14510,C14520,C14530,C17200,C19200,C21000,C23000,C26000 ,C27000,C27400,C28000,C33000,C33200,C37000,C44300,C44400, C44500,C60800,C63020,C65500,C68700,C70400,C70600,C70620, C71000,C71500,C71520,C71640,C72200,etc.
4.	Diameter	1-500mm
5.	Surface	mill,polished,bright,oiled,hair line,brush,mirror,sand blast,or as required.
6.	Price Term	Ex-work, FOB, CFR, CIF, etc.
7.	Payment Term	T/T, L/C, Western Union, etc.
8.	Delivery Time	According to order's quantity.
9.	Package	Export standard package: bundled wooden box, suit for all kinds of transport, or be required.
10.	MOQ	300kg
11	Application	Copper products are widely used in aviation, aerospace, ships, military industry, metallurgy, electronics, electrical, mechanical, transportation, construction and other fields of the national economy.
12	Contact	If you have any question, please feel free to contact me.

The products are mainly used in nuclear power, hydropower, shipbuilding, metallurgy, chemical industry and other fields. Product availability: 0.3-150mm thick; Width: 200-3100mm; Length ≤ 8000mm.
Rolled Products
ZYTC is your source for a very large range of brass, bronze, and copper rolled products with extremely fast deliveries and very competitive pricing! Our mill can offer coinage quality material for minting applications, and high-quality strip for defense and automotive applications. We also can provide bullet jacket cups and cartridge case cups for all standard calibers in large volumes.
Some of the Industries Served: ·Automotive ·Defense/ammunition ·Antimicrobial ·Building and Construction ·Coinage ·Electrical ·Data and Communications

GRADE	TECHNOLOGY	TEMPER	SPECIFICATION(MM)
			THICKNESS	WIDTH	LENGTH
COPPER & BRASS & BRONZE	HOT ROLLED	M20	4~8	600~3100	≤6000
			>8~150	200~3100	≤6000
	COLD ROLLED	O60,H01,H02,H04,H06,H08	0.3~<0.5	400~610	≤2000
			0.5~3.0	400~1020	≤3000
			>3.0~12	400~3100	≤8000

BRASS ALLOYS

UNS (USA)	ASTM	EN Symbol	EN No	BS (UK)	JIS (Japan)
C22000	B-36, B0130, B-131	CuZn10	CW501L	CZ101	C22000
C23000	B-36, B-569, B-888	CuZn15	CW502L	CZ102	C23000
-		CuZn28	CW504L	-	-
C26000	B-19, B-36, B-888	CuZn30	CW505L	CZ106	C26000
C26800	B-36	CuZn33	CW506L	CZ107	C26800
C27000	B-36	CuZn36	CW507L	CZ107	C27000
C27200	B-36	CuZn37	CW508L	CZ108	C27200
C28000	B-36	CuZn40	CW509L	CZ109	C28000

Chemical Composition

Alloy	Cu	Zn	Al	Fe	Ni	Pb	Sn
C22000	89.0-91.0	Rem	0.02	0.05	0.30	0.05	0.10
C23000	84.0-86.0	Rem	0.02	0.05	0.30	0.05	0.10
-	71.0-73.0	Rem	0.02	0.05	0.30	0.05	0.10
C26000	69.0-71.0	Rem	0.02	0.05	0.30	0.05	0.10
C26800	66.0-68.0	Rem	0.02	0.05	0.30	0.05	0.10
C27000	63.5-65.5	Rem	0.02	0.05	0.30	0.05	0.10
C27200	62.0-64.0	Rem	0.05	0.10	0.30	0.10	0.10

General Characteristics	Applications
Good Electrical and Thermal Conductivity Good Corrosion Resistance Perfect for Cold Forming and Machining Perfect Strength Good for Welding, Soldering, and Plating	Primer Cups Bullet Jacket Cups Cartridge Case Cups Architectural Industry Construction Industry Electronic Industry Automotive Industry Sanitary Ware Defense Industry Machinery Equipment Decoration, Jewelry

FAQ:
Q1:How long time is the shortest delivery?
A1:For stock material,the delivery time is just 3-5 working days.
And for customized product,it will takes 25-35 working days based on different size and quantity.
Q2:Can you supply the sample?Does it free or not?
A2:For partial materials,we can supply the sample free(without the freight charge).
If you want to know more details,please contact our sales online.
Q3:What's the terms of payment?
A3:We can accept T/T,100% irrevocable LC at sight,Western Union,etc,
Q4:How to ensure the quality?
A4: We can supply QC,such as MTC,SGS, UT Certificate,etc.

If our quality is unapproved,we need and will refund full payment to customers
Q4.How can we get your price ?
We need below information to quote for you:
1. Product Name
2. Standard
3. Material Grade (Chemical Composition)
4. Dimension
5. Quantity
6. The Drawing for Special Parts
