Business Machines 2024 Maxi Roll Paper Towel Cutting Machine

Product Description

Product Details
Business machines 2024 maxi roll paper towel cutting machine
Product Description
The equipment is operated by using PLC program control, big screen true color human-computer interface. The precise servo control feed length, electromechanical integration control and other international advanced technology con automatically detect each key action, has good fault information prompt system, make the whole production line achieving the best working state.
Features:
1. The transducer independent driver is used in the main motor;
2. The cutting knife automatically stops and gives an alarm;
3. When the paper can't be cut down, the equipment will stop and ask you to set the cutting depth.
4. The high precision servo system is used in the feed motor servo system, to ensure the quality of the finished product;
5. The equipment automatically calculate the quantity of the finished product being cut; according to the raw material and the length of the finished product;
6. When data input is incorrect, the equipment breaks off and prompts to adjust on the interface;
7. Cut with knife is used in the equipment, which reduce the use cost of the user;
8. The automatic sharpening knife system is used in the equipment, can adjust the sharpening knife system according the requirement of paper being cut, which increase the cutting life;
9. The sharp steel wheel is used in the sharpening knife system, which increase the sharpening knife efficiency 10.The thickness of finished paper core should be less 4.15mm
Technical data

Cutting speed	15-20cuts/minute
Cutting channel	single channel
Cutting blade	band saw blade
Cutting blade size	5180*100*1.05
Log length	Max. 2900mm
Tolerance	±1mm
Cutting length	Max. 250mm
Cutting diameter	150/300mm(No need to change moulds)
Thickness of paper core	Max.4.5 mm
Power supply	3 phase 4line 380V 60HZ
Machine weight	3000KG
Overall size of machine	4250*3350*2300mm
Separated size	Main machine: 4250*1700*2000mm
	Paper storage: 1500*1650*1300mm
