CNC Skiving and Burnishing Machine for Deep Hole Cylinder

Product Description

CNC Skiving and Roller Burnishing Machine For Deep Hole Cylinder
DSBK-150 DSBK-200 DSBK-250 DSBK-360 DSBK-500
Machine Summary:
*The CNC skiving roller burnishing machine is newly developed by our company. This machine has the smart and simple CNC operation system with high efficiency and stable performance, the configuration design is uniform, artistic and clean, using the environmental protection measures against oil splash and leakage.

Performance and Features:
*When processing, the workpiece is fixed and the tool is rotated. Adopting the combined technology of skiving and roller burnishing, the machine gives a good solution for the severe deviation in rough processing of hot roller steel tube, and the inferior straightness in fine procssing of cold drawn steel tube.
*It is mainly used for the compound process of boring and roller burnishing for hydraulic cylinder parts.
*The hole tolerance is up to IT7-8, the surface roughness is up to Ra 0.2-0.4 µm. Its processing efficiency is 10 times of the traditional boring technology and 20 times of ordinary honing machines. The traditional technology usually includes four independent steps in ordor: rough boring-semi fine boring-floating boring-roller burnishing, which is inefficient and needs a long time.
*This machine is assembled with automated flexible tools control module, using the specialized Korean pneumatic and Germany hydraulic tools system, the stock removal within 0.2-8mm is available to be processed.
*The series machines adopt Germany Siemens 808 CNC system, the spindle box is driven by AC variable frequency motor, with stepless speed regulating, and using spindle bearing with a high ratary precision.
*Feeding box is driven by AC servo motor, with stepless speed regulating. The bed body adopts high quality cast iron, the double track ensures the good rigidity and excellent guiding, with protection structure around.
*The machine is equipped with the automatic chips removal, magnetic separator and paper filter, filtering precision up to 20µm, the coolant can be cleanly recycled and reutilized.
Technical Parameters

Specifications	Units	DSBK-150	DSBK-200/DSBK-250
Boring dia. range	mm	Φ35-Φ150	Φ40-Φ200/250
Processing depth range	m	1-12	1-12
Machine guideway width	mm	500	650
Spindle center height	mm	300	350
The spindle speed range, grades	r/min	5-1200 (stepless)	120-1000 (4shifts stepless)
Main motor power	kw	30	30/60 (variable frequency)
Feed speed range	mm/min	5-3000 (stepless)	5-3000 (stepless)
Feed carriage rapid moving speed	m/min	3/6	3/6
Workpiece clamping diameter range	mm	Φ40-Φ150	Φ40-Φ300/350
The feed motor torque	N.m	27	36
Cooling pump motor	kw	N=5.5 (two group)	N=5.5 (three group)
The hydraulic pump motor	kw	/	1.5kw, n=1440r/min
Cooling system rated pressure	MPa	2.5	2.5
The cooling system flow	L/min	200, 200 (two group)	100, 200, 200 (three group)
Air pressure	MPa	≥0.4	≥0.4
Numerical control system		SIEMENS 808

Specifications	Units	DBSK-360	DBSK-500
Boring dia. range	mm	Φ60-Φ360	Φ120-Φ500
Boring depth range	m	1-12	1-12
The width of guideway	mm	650/800	800
Spindle center height	mm	450	625
Spindle speed change range	r/min	60-1000 (4shifts, stepless)	5-1000 (4shifts, stepless)
Main motor power	kw	60/75 (variable frequency)	75/110 (variable frequency)
Feed speed range	mm/min	5-3000 (stepless)	5-3000 (stepless)
Feed carriage rapid moving speed	m/min	3/6	3/6
Workpiece clamping diameter range	mm	Φ120-Φ450	Φ120-Φ550
Feed motor torque	N.m	48	50
Cooling pump motor power	kw	N=7.5 (three group)	N=7.5 (three group)
Hydraulic pump motor power	kw	1.5kw, n=1440r/min	1.5kw, n=1440r/min
Cooling system rated pressure	MPa	2.5	2.5
Cooling system flow	L/min	200, 200, 200 (three group)	300, 300, 300 (three group)
Air pressure	MPa	≥0.4	≥0.4
Control system		SIEMENS 808	SIEMENS 828

Spindle box and Guideway
*Spindle box adopts high precision and high quality bearings, to guarantee processing accuracy and stable operation.
*Guideway adopts high quality cast iron, the one V-type and flat track ensure the giridity and good guiding.
Packaging & Shipping
Firstly packed by waterproof cloth and then in wooden case.
Few parts may need to be taken down and be packed in wooden case.
According to customer's different require, wo can adopt different packaging.
Whether CNC deep hole honing machine or CNC deep hole drilling and boring machine or CNC deep hole skiving roller burnishing machine, we all use the same standard Packagings.
