Variable Speed Bench Metal Lathe Machine CZ1340V CZ1440V CZ1237V
| US$2,000.00-3,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
CZ1340V CZ1440V CZ1237V
Type
Horizontal Lathe
Processing Accessory
Metal
Guide Rail
Horizontal Guide Rail
Tool Holder
4 Way Tool Post
Power Source
Electric
Controlling Mode
Artificial
Automatic Grade
Manual
Setting Mode
Floor-type
Precision
Normal Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Max.Swing Over Bed
305mm
Max. Swing Over Gap
440mm
Spindle Taper
Mt5
Width of Bed-Way
182
Transport Package
Plywood Case
Trademark
HOYONG-TRD
Origin
Shandong, China
HS Code
84581900
Production Capacity
100 PCS/Month
Product Description
| ITEM | CZ1340V | CZ1440V | CZ1237V | |
| Swing over bed | mm | φ330 | φ355 | φ305 |
| Swing over carriage | mm | φ195 | φ220 | φ173 |
| Swing over gap | mm | φ476 | φ500 | φ440 |
| Width of bed-way | mm | 186 | 186 | 182 |
| Distance between centers | mm | 1000 | 1000 | 940 |
| Spindle taper | M.T.5 | M.T.5 | M.T.5 | |
| Spindle bore | mm | φ38 | φ38 | φ38 |
| Step of speed | Variable | Variable speed | Variable | |
| Range of speed | rpm | Low 70~480 | low : 70~480 | Low 70~520 |
| high 480~2000 | high: 480-2000 | High 520~1700 | ||
| Head | D1-4 | D1-4 | D1-4 | |
| Metric thread | 26kinds (0.4~7mm) | 26kinds (0.4~7mm) | 26kinds (0.4~7 mm) | |
| Inch thread | 34kinds(4~56T.P.I) | 34kinds(4~56T.P.I) | 34kinds(4~56T.P.I) | |
| Moulder thread | 16 kinds(0.35~5M.P) | 16 kinds(0.35~5M.P) | ||
| Diametral thread | 36 kinds(6~104D.P) | 36 kinds(6~104D.P) | ||
| Longitudinal feeds | mm/r | 0.052~1.392 (0.002"~0.0548") | 0.052~1.392 (0.002"~0.0548") | 0.052~1.392 (0.002"~0.0548") |
| Cross feeds | mm/r | 0.014~0.38 (0.00055"~0.015") | 0.014~0.38 (0.00055"~0.015") | 0.014~0.38 (0.0007"~0.0187") |
| Diameter lead screw | mm | φ22(7/8") | φ22(7/8") | φ22(7/8") |
| Pitch of lead screw | 3mm or 8T.P.I | 3mm or 8T.P.I | 3mm or 8T.P.I | |
| Saddle travel | mm | 1000 | 1000 | 810 |
| Cross travel | mm | 170 | 170 | 150 |
| Compound travel | mm | 74 | 74 | 90 |
| Compound travel | mm | 95 | 95 | 100 |
| Barrel diameter | mm | φ32 | φ32 | φ32 |
| Taper of center | mm | M.T.3 | M.T.3 | M.T.3 |
| Motor power | Kw | 1.5(2HP) | 1.5(2HP) | 1.5(2HP) |
| Motor for coolant system's power | Kw | 0.04(0.055HP) | 0.04(0.055HP) | 0.04(0.055HP) |
| Machine(L×W×H) | mm | 1920×760×760 | 1920×760×760 | 1780×750×760 |
| Stand(left) (L×W×H) | mm | 440×410×700 | 440×410×700 | 400×370×700 |
| Stand(right) (L×W×H) | mm | 370×410×700 | 370×410×700 | 300×370×700 |
| Machine | Kg | 500/560 | 505/565 | 390/440 |
| Stand | Kg | 70/75 | 70/75 | 60/65 |
