5in1 Xvr Hybrid Recorder for Ahd Tvi Cvi IP Cameras Onvif CCTV Security

Product Description

Product Description
Introducing the 8MN 8CH XVR Onvif CCTV DVR Hybrid Recorder! Get ready to take your surveillance game to the next level with this incredible 5IN1 XVR. Designed for AHD, TVI, CVI, CVBS, and IP cameras, this hybrid recorder offers unparalleled versatility and adaptability.
With support for both H.265 and H.264 video formats, you can enjoy high-quality video footage without compromising on storage space. But that's not all - this XVR also supports audio over coaxial cable, allowing you to capture not just visuals, but also audio for a complete surveillance experience.
Equipped with 8-channel BNC input, this XVR ensures that you can connect multiple cameras effortlessly. And with 1-ch HDMI output and 1-ch VGA output at up to 1920*1080 resolution, you can view your footage in stunning clarity on your preferred display.
One of the standout features of this XVR is its long transmission distance over coaxial cable. No need to worry about signal loss or degradation - this XVR ensures that your footage is transmitted seamlessly over long distances.
From Veacam Electronics Co., Ltd, a trusted name in the industry, comes the 5in1 XVR Hybrid Recorder for AHD, TVI, CVI, and IP cameras. This hybrid recorder is perfect for anyone looking to enhance their security camera setup. Whether you need it for your home, office, or any other space, this XVR is the ultimate solution.
So why wait? Upgrade your surveillance system today with the 8MN 8CH XVR Onvif CCTV DVR Hybrid Recorder. Don't miss out on this opportunity to experience top-notch security and peace of mind. Get yours now! Product Parameters

Model	VCXVR-808UA1S
Video/Audio Input
Analog Video Input	4-ch, BNC
IP Video Input	2-ch(only IP up to 6ch), each channel up to 4K
Supported Analog Camera Types	Support AHD input: 8MP@15fps(channel1) 5MP@20fps 4MP@30fps 3MP@30fps(channel1) 1080P@30fps 720P@60fps Support TVI input: 8MP@15fps(channel1) 5MP@20fps 4MP@30fps 3MP@20fps (channel1) 1080P@30fps 720P@60fps Support CVI input: 8MP@15fps(channel1) 5MP@20fps 4MP@30fps 1080P@30fps 720P@30fps Support CVBS input
Audio Input	1-ch, RCA
Two-way Audio	1-ch, RCA
Network
Incoming Bandwidth	48Mbps
Outgoing Bandwidth	60Mbps
Remote Users	128
Protocols	TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE
Video/Audio Output
CVBS Output	1-ch, BNC
VGA Output	1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
HDMI Output	1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
Audio Output	1-ch, RCA
Synchronous Playback	4-ch
Encoding
Recording Resolution	8MP Lite/5MP Lite/4MP Lite /3MP/1080P/960P/720P/960H/4CIF/CIF
Recording Frame Rate	Main stream: 8MP Lite@8fps(channel1) 5MP Lite@12fps 4MP Lite@15fps 3MP@15fps(channel1) 2MP@15fps 720P@30fps Sub stream: D1@30fps(Max)
Hard Disk
SATA	1 SATA interface
Capacity	Up to 6TB for each HDD
External Interface
Network Interface	1 RJ45 10M/100M self-adaptive Ethernet Interface
USB Interface	Rear panel: 2 x USB2.0
Serial Interface	1 x RS485
General
Power Supply	12V DC Power Consumption: ≤ 8 W( without HDD )
Working Environment	-10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing)
Dimensions(W×D×H)	260mm ×240mm× 46mm (10.2" × 9.4"×1.8")
Weight ( without HDD )	≤1.1 Kg ( 4.19lb )

Detailed Photos

Company Profile
Certifications
Our Advantages

FAQ
Introducing our incredible High Definition 5MP True WDR Network Camera with Human Detection and Built-in Mic, brought to you by the amazing team at Veacam Electronics Co., Ltd. Get ready to experience top-notch security and peace of mind like never before!
Prepare to be blown away by the high definition capabilities of this camera. It delivers crystal clear images and videos that will leave you in awe. Every detail is captured with precision, ensuring that nothing goes unnoticed. And with the True WDR technology, even challenging lighting conditions won't stand in the way of optimal image quality. You can trust that your surveillance footage will be accurate and reliable.
But that's not all! This camera is equipped with advanced human detection technology that is truly mind-blowing. It can intelligently identify human movements, so you won't have to deal with annoying false alarms. You'll only be alerted when it's absolutely necessary. And with the built-in microphone, you can enjoy clear audio recording that enhances your overall surveillance experience.
Worried about the elements? Don't be! This camera is designed for outdoor use and is completely waterproof and weatherproof. It can handle any environment with ease. Its durable construction ensures long-lasting performance, even in harsh conditions. Plus, the IP67 rating guarantees protection against dust and water, so you can rely on it to operate flawlessly at all times.
Installing this camera is a breeze, and it offers flexible connectivity options that seamlessly integrate into your existing security system. We've got you covered when it comes to shipping too. Whether you prefer DHL/UPS/Fedex or other air and sea shipments, we can accommodate your preferences.
At Veacam Electronics Co., Ltd, customer satisfaction is our top priority. That's why we offer various payment methods, including T/T, LC, Western Union, and Trade Assurance, to ensure a convenient and secure transaction process. We're all about customization too! You can even print your logo on the product, making it uniquely yours. And depending on your requirements, we can adjust the minimum order quantity to suit your needs. We even support small test orders for all customers.
If you're still not convinced, we offer samples for a fee so you can experience the quality of our product firsthand. And here's the best part - the sample fee will be refunded in your later order. So you have nothing to lose!
Don't let this opportunity slip through your fingers. Enhance your security system with our extraordinary High Definition 5MP True WDR Network Camera with Human Detection and Built-in Mic. Contact us now for more details and let us help you achieve unparalleled surveillance.
