BestScope BS-2020M Economic LED Education Student Outdoor Easy Use Biological Microscope

US$255.00 1 Piece (MOQ)

Basic Info.

Model NO.

BS-2020M

Type

Biological

Number of Cylinder

Monocular

Mobility

Desktop

Kind of Light Source

Ordinary Light

Shape

Cylindrical Shaped Lens

Usage

Teaching, Research

Principle

Optics

Principle of Optics

Biological Microscope

Eyepiece

WF10X/18mm

Objective

Achromatic Objective 4X, 10X, 40X, 100x(Oil)

Nosepiece

Backward Quadruple Nosepiece

Stage

Double Layer Mechanical Stage 132X142mm/ 75X40mm

Focusing

Coaxial Coarse & Fine Adjustment

Condenser

Abbe NA 1.20 with Iris Diaphram and Filter

Illumination

1W S-LED illumination, Brightness Adjustable

Transport Package

Strong Carton with Polyfoam Protection

Trademark

BestScope

Origin

China

Production Capacity

1000 Sets Per Month

Product Description

IntroductionBS-2020 series microscopes are economic, practical and easy to operate. These microscopes adopt LED illumination, which saves energy, has long working life and also comfortable for observation. These microscopes are widely used in educational, academic, agricultural and study field. With a microscope adapter, a digital camera (or digital eyepiece) can be plug into the trinocular tube or the eyepiece tube. Built-in rechargeable battery is optional for outdoors operation or places that power supply is not stable. Feature1. Comfortable operation with updated and ergonomic design;
2. LED light illumination, save energy and long working life;
3. Compact and flexible, ideally suited for desktop, laboratory worktable. ApplicationBS-2020 series microscopes are ideally suited for school biological education and medical analyses area to observe all kinds of slides. They can be widely used in clinics, hospitals, schools, academic labs and scientific research department. Specification

Item	Specification	BS-2020M	BS-2020B	BS-2020T
Viewing Head	Monocular Head, Inclined at 30°, 360° Rotatable	*
	Seidentopf Binocular Head, Inclined at 30°, 360° Rotatable, Interpupilary Distance 48-75mm		*
	Seidentopf Trinocular Head, Inclined at 30°, 360° Rotatable, Interpupilary Distance 55-75mm			*
Eyepiece	WF10×/18mm	*	*	*
	WF16×/11mm	○	○	○
	WF25×/8mm	○	○	○
Objective	Achromatic Objective 4×, 10×, 40×, 100×(Oil)	*	*	*
Objective	Achromatic Objective 20×, 60×	○	○	○
Nosepiece	Backward Quadruple Nosepiece	*	*	*
Stage	Double Layer Mechanical Stage 132×142mm/ 75×40mm	*	*	*
Focusing	Coaxial Coarse & Fine Adjustment, Fine Division 0.004mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.4mm per Rotation, Moving Range 24mm	*	*	*
Condenser	Abbe NA 1.20 with Iris Diaphram and Filter	*	*	*
Illumination	1W S-LED illumination, Brightness Adjustable	*	*	*
Illumination	Halogen Lamp 6V/ 20W, Brightness Adjustable	○	○	○
Immersion oil	5ml Immersion oil	*	*	*
Optional Accessories	Phase Contrast Kit	○	○	○
	Dark Field Attachment	○	○	○
	Polarization Attachment	○	○	○
	Rechargeable battery	○	○	○
Package	1pc/carton, 39.5cm26.5cm50cm, 7kg	*	*	*

Note: *Standard Outfit, ○ Optional
Sample Images
