Advanced Plastic Injection Molding Machine for Diverse Applications
Basic Info.
Model NO.
HTF-108/JD
Type
Injection Molding Machine
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Non-Computerized
Certification
CE, ISO9001:2008
Screw Diameter
32mm
Screw L/D Ratio
23
Shot Size(Theoretical)
144
Injection Rate
81
Injection Pressure
207
Clamping Force
1080km
Space Between Tie Bars
360*360mm
Heater Power
6.3kw
Machine Weight
2.9t
Transport Package
Stretch Film
Specification
HTF-108/JD
Trademark
Haituo
Origin
China
HS Code
8477101090
Production Capacity
200
Packaging & Delivery
Package Size
5000.00cm * 4000.00cm * 3000.00cm
Package Gross Weight
2000.000kg
Product Description
FAQ1. Who are we?
We are based in Zhejiang, China, start from 2017,sell to South America(20.00%),Mid East(20.00%),Southeast Asia(15.00%),Africa(13.00%),Eastern Europe(10.00%),Eastern Asia(10.00%),South Asia(5.00%),North America(1.00%),Oceania(1.00%),Western Europe(1.00%),Central America(1.00%),Northern Europe(1.00%),Southern Europe(1.00%),Domestic Market(1.00%). There are total about 11-50 people in our office.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3. What can you buy from us? Injection molding machine, plastic machinery, plastic mold, blow molding machine, plastic auxiliary equipment
4. Why should you buy from us not from other suppliers?
Energy-saving servo, higher precision, clamping force 500KN-30000KN, European safety standards, more than 30 years experience in injection molding machines, better quality than other companies, 100% real factory, cheaper price, 24 hours best service.
5. What services can we provide?
Accepted delivery terms: FOB,CFR,CIF,EXW,DDP,DDU,express delivery,DAF,DES;
Accepted payment currency: USD,EUR,HKD,CNY;
Accepted payment type: T/T,L/C,PayPal,Western Union,cash;
Spoken language: English, Chinese, Spanish, Portuguese, Arabic, Russian, Hindi
| INTERNATIONAL SPECIFICATION | NO | HTF-170/JD | ||
| INJECTION UNIT | A | B | C | |
| Screw Diameter | MM | 32 | 35 | 38 |
| Screw L/D Ratio | L/D | 23 | 21.2 | 19 |
| Shot Size(Theoretical) | CM3 | 144 | 173 | 202 |
| Injection Weight(PS) | G | 130 | 155 | 181 |
| Injection Rate | G/S | 81 | 110 | 143 |
| Injection Pressure | MPA | 207 | 183 | 175 |
| Screw Speed | RPM | 0~220v | ||
| CLAMPING UNIT | ||||
| Clamping Force | KN | 1080 | ||
| Toggle Stroke | MM | 320 | ||
| Space Between Tie Bars(W*H) | MM | 360*360 | ||
| Max.Mold Height | MM | 370 | ||
| Min.Mold Height | MM | 150 | ||
| Ejector Stroke | MM | 90 | ||
| Ejector Force | KN | 28 | ||
| Ejector Rods Number | PC | 5 | ||
| OTHERS | ||||
| Max.Pump Pressure | MPA | 16 | ||
| Pump Motor Power | KW | 13 | ||
| Heater Power | KW | 6.3 | ||
| Machine Dimension(L*W*H) | M | 4.1*1.15*1.7 | ||
| Machine Weight | T | 2.9 | ||
