Screwed End Floating Ball Valve Shut Down Valve

Product Description

Screwed Floating Ball valve is mainly used to cut off, distribute and change the flow direction of medium in pipeline.It has the characteristics of small volume, reliable sealing performance, simple structure, convenient maintenance and strong corrosion resistance


Specification Size:1/2"~2",DN 15~DN 50
Pressure:Class 150~Class 2500,PN 16~PN 420
End connection:Flanged,Welded

Main Material Casting Steel:WCB,WCC,WC6,WC9,LCB,LCC,CF8,CF3,CF8M,CF3M,CF8C,4A,5A,6A,CN7M,CW6MC,
CW12MW,CU5MCuC,C5,C12,M35-1
Forged Steel:A105,F11,F22,LF2,F304,F304L,F316,F316L,F321,Alloy 20,N06625,F5,F9,F51,F53,F55
Special Alloy Steel:Inconel,Hastelloy,Monel

Products Standard And Features Std:
1.Design & manufacture:API 6D
2.Flange END:ASME B16.5
3.Face To Face :ASME B16.10
4.Butt end:ASME B16.25
5.Inspection & Test:API 598

Feature:
1. Full bore or reduced bore
2. Floating ball
3. Split body
4. Screwed end
5. Anti-static device
6. Blow-out proof stem
7. Low flow resistance
8. Simple structure
9. Small volume and light weight
10. The sealing surface of the ball valve is made of plastic with good sealing performance
11. Convenient operation,quick opening and closing, convenient for remote control
12. It is easy to maintain.The sealing ring is generally movable.It is easy to disassemble and replace
13. When fully open or fully closed,the sealing surface of the ball and valve seat is isolated from the medium,and the medium will not cause erosion of the valve sealing surface
14. It is not limited by the installation direction,and the flow direction of media can be arbitrary
15. On request,any other tests can be carried out according to the customer's special instructions
