Customerized Va Type Monochrome Small Size LCD Screen Display
Basic Info.
Model NO.
8D0030
Aspect ratio
4:3
Feature
Touch Display, LED Backlight Display, With Remote Control, Tn Va Silk Prin Screen Display
Optimum Resolution
3840x2160
Type
TN
Widescreen
Widescreen
Response Time
2ms
3D
Not 3D
Interface Type
COB, Cog, Tab
LCD Type
Va LCD Module
LCD Operating Voltage
5.0V
Driving Method
1/4duty ,1/3bias
Viewing Angle
12:00 Viewing
Polarizer
Transmissive,Negative
Operater Temp
-20-70degree
Storge Temp
-30-80 Degree
Connector
Pin Connector
Customerize
Yes
Wrannty
50000h
Transport Package
Cartons, Foam Box
Specification
SGS ROHS
Trademark
better
Origin
Shenzhen, Guangdong, China
HS Code
9001200001
Production Capacity
50000PCS/M
Product Description
Customerized Monochrome small size LCD screen displaySpec:
SIZE:86.3*41*38mm
DISPLAY TYPE: VA TN DISPLAY
LCD OPERATIONG VOLTAGE :5.0v?(3V-5V.>2.8V IS OK)
OPERATING TEMP:-20-70C
STORGER TEMP:-30-80C
DRIVE MODE: 1/4DUTY ,1/3BIAS
VIEWING DIRECTION: 6H(BOTTOM VIEWING)---(12H,6H,3H,9H)
POLARIZER TYPE: FRONT :TRANSMISSIVE,
BACK: TRANSMISSIVE
CONNECTOR: PIN (24)
SCREEN PRINT: three COLORS
BACKLIHGT: WHITE WITH TWO LIGHT,/BLUE BL (CUSTOMER DESIGN)
VA type LCD panel:
1, High -contrast
2,sale-price&multicolor
3,Wide temperature
4,Applies to vehicle, audio products and meters
All lcd display 100% test before delivery
accepted customer design lcd
accepted LCD PANEL &LCD module OEM
| ITEMS | TN- TYPE | HTN-TYPE | STN-TYPE | FSTN-TYPE | VA-TYPE | |||
| Viewing Angle | 60º | 75º | 115º | 150º | 165º | |||
| Contrast | nomal | nomal | good | high contrast | high contrast | |||
| Advantages | 1,easyly made 2,sales price 3,nomal materials 4,nomal product for black-white display | 1,viewing angle wider than TN | 1,wide viewing angle 2,multi-display 3,wide range application 4, High -road driving | 1,nearly whole viewing angle 2, multi-display 3,wide-range application 4,High-road driving | 1,nearly whole viewing angle 2, multi-display 3,wide-range application 4,High-road driving 5,with color silk printing | |||
| Disadvantages | 1,low viewing angle 2,sigle display model 3 lower driving method. | Contrast nomally | 1,Complex manufacturing process 2,High cost. | 1,Complex manufacturing process 2,High cost. | 1,Complex manufacturing process 2,High cost. | |||
Bitmap Bitmap Bitmap Bitmap
| Caculator, Telephone, nomall electronic products | Instruments and Industrial meters | Bitmap Bitmap
| High-grade Instrument and meter | Bitmap Bitmap
| |||
| Picture show | Bitmap Bitmap | |||||||
