Escalator From China Manufacturer

Product Description

Designing and Styles mingled with mordern atmosphere
With Incorporation of the well-developed escalator technology, advanced micro-computer control system, high strength truss structure, classical driving system and completed safety dvices. IE20 series of escalator full ensure our products safe, reliable, endurable and bring steady and comfortable riding. Complying with European standard EN115, our escalator are applicable for heavy passenger flow location such as market, supermarket, hotel , subway, airport and railway station etc.
-- Streamlined handrail system in stainless steel refelcts noble sytle of western Europe with its 180 degree arc end and black inlet.
-- Advanced control system and driving device, superior driving chain, excellent workmanship assures the safe, reliable and satable operation.
-- The safety protection functions as many as 21 items fully comply with national and European standard.
-- Automatic lubrication system lubricates all kinds of driving components which prolongs products' operation life greatly.
-- The application of VVVF drive (optional) marks escalator be a representation energy saving product. By checking the traffic flow timely by means of photo electrical sensor located at the entrance of escalator, achieving auto moving with great energy saved.
-- Micro-computer controlled system performs with rapid calculation speed, high reliable moving, and also with failure code fixed, easy to be maintained.
-- Drive device arranged vertically assures enough space and convinience for maintenance.
IE20 Escalator Standard specification

Application	Indoor, outdoor, 16-Hr operation daily
Rise (m)	<= 6	<=7.5
Inclination (degree)	35	30
step width (mm)	600/800/1000
Horizontal steps	2/2	2/2 or 3/3
speed ( m/s)	0.5
main power	380V/50Hz/3P
balustrade	tempered glass (10mm)
handrail bracket	stainless steel
handrail color	black
balustrade height	900 mm
innter & outer decking	hairline stainless steel
skirting	hairline stainless steel
step	stainless steel / aluminum alloy
landing plate	Anti sliding stainless steel
illumination	lighting under upper/lower landing steps
Indicator	failure code indicator on control cabinet
Operation	emergency stop button, key switch, inspection operation
