High Quality Infrared Lab Textile Dyeing Machine

Product Description

Product Description
Product DescriptionAT272 Series Infrared Lab Dyeing Machine (original model HY0140) is the newest infrared lab dyeing machine. It combines the advantages of common infrared machines and high temperature glycerol machines; also it overcomes their deficiencies of large material consumption and pollution.SpecificationModelAT272 SeriesDyeing pot numbers12, 16, 18, 24 selectableDyeing pot volume200ml, 300ml, 350ml, 450ml,500ml selectableTemperature rangeRT.~ 140oCMax. heating rate5oC/minTemperature accuracy±0.5Liquor ratio1:5 ~ 1:100Rotation speed0 ~ 60 rpmHeating systemInfraredCooling systemAirPower supply220V, 50Hz,Dimensions660*680*780mmWeight120kgDetails & Features★ Intelligent design for chemical lid, easy to add dose chemicals during the dyeing process without opening the lid (optional)★ Equipped with a programmable intelligent computer control★ Up to 64 test program settable★ Adopt solid state relay to control temperature, makes it more accuracy and uniform★ It use infrared heating system which is low power consumption, no smoking pollution and loss of glycerol, it has good thermal insulation effect and is effective in saving energy and costs.★ 360o tumbling rotation make the dyeing more uniform and is widely used for all fabric★ It used air cooling system without using water and cut down the cost.★ It can work at different liquor ratio from 1:5 to 1:100. It can be matched with spray dyeing machine.★ The body is made of stainless, good appearance and durable.★ Different working position and dyeing pot volume selectable.Our CompanyHistorySince 1982 with more than 20 years’ experienceWarrantyTwo Year Warranty for whole productTrainingVideo and user manual for trainingOnsite serviceInstallation and training service is availableTesting serviceFree sample testing before order is availableLead time15 working days lead time for most productPacking & DeliveryPackagingDimensions660*680*780mmWeight120kgPackaging Details1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. PaymentPayment TermT/TEXW30% T/T in advance, paid the balance before shipmentFOBCFR(C&F)30% T/T in advance, paid the balance against copy of B/LCIFL/CL/C amount above 50,000 usd, we can accept L/C at sightWest UnionAmount lower than 5000usdWest UnionDelivery Time7~10days after receiving payment for one containerContacting Us
