China Heavy Duty Hydraulic Clamping Radial Drilling Machine (Z3063X20A)

Product Description

China Heavy duty Hydraulic clamping radial drilling machine (Z3063x20A) Product Description

Radial drilling machine, can also be called radial drill. Radial drilling machine is a hole processing equipment, can be used to drilling, reaming, reaming, tapping and scratching the end of the various forms of processing.
According to the machine clamping structure classification,radial drilling machine can be divided intohydraulic radial drilling machine and mechanical radial drilling machine. In all kinds of drilling machine, radial drilling machine is easy to operate, flexible, wide range of applications, with a typical, especially for single or Batch production with porous large parts of the hole processing, is the general mechanical processing workshop common machine tools.
Main Features:
1.Hydraulic speed changing, Hydraulic column clamping.
2.Oversize base plate, ideal for processing of large workpieces
3.Torsion-free, polished column promotes sliding capacity of radial arm
4.Radial arm and drill head feature independent hydraulic clamp
5.Lifting motor allows for easy height adjustment of radial arm
6. Ideal for drilling, countersinking, reaming and tapping
7. Hardened, polished gears in oil bath
8. Polished surface ensures for smooth movement of drill head on radial arm
9.Heavy Duty Precision manufactured radial arm drilling machines
10.Hydraulic column & head clamp ensures fixed tool positioning
11.Oil-bath lubricated gearbox with hardened & ground gears
12.16 speed auto down-feed: 0.04 ~ 3.2 (mm/rev)
13.Unique hydraulic operated feed & spindle drive system
14.Arm height adjusted via vertical leadscrew & heavy duty induction motor
15.High quality fine grain cast iron with ribbing ensures extremely low vibration
16.Coolant pump system with flexible hose
17.Work light mounted underneath arm providing direct light on work piece
Product Parameters

Please check the detailed pictures of our Z3063x20A Heavy duty Hydraulic clamping radial drilling machine as following:

Model	Z3063×20A
Max. Drilling capacity (mm)	63
Distance spindle axis to column generating line (mm)	450-2050
Diameter of column (mm)	450
Spindle taper	MT5
Spindle travel (mm)	400
Spindle speeds range (r/min)	20-1600
Spindle speeds series	16
Range of Spindle feeds (r/min)	0.04-3.2
Spindle feeds	16
Max. Distance spindle nose to working surface of base (mm)	400-1600
Dimension of worktable (mm)	960x630x500
Dimension of base (mm)	2900x1250x250
Overall Size (mm)	3110x1250x3150
Power of Main motor (KW)	5.5
G.W/N.W (kg)	8000/7000
Packing dimension (cm)	347x147x235

Standard accessories:
1.Box shape worktable
2.taper sleeve
3.tool releasing wrench
4.drift
5.eyelet bolts

Optional accessories:
1.quick instead chuck
2.tapping chuck
3.grease gun Detailed Photos

Packaging & Shipping


HS CODE:8459290
PACKAGE:1 PCAKAGE
if you booking vessel ,pls booking a 40HC . even if it's LCL
Payment:Bank TT
30% down payment is enough ,70% balance agaist B/L.
