Cw62100dx3000 Metal Heavy Duty Lathe Machine

Product Description

Product Description

FEATURE:
1. These robust and versatile lathes are engineered to expertly turn end-faces, cylindrical surfaces, and internal holes with precision and ease.
Additionally, they are adept at crafting a wide range of threads, including metric, inch, module, and pitch threads, tailoring to all your intricate engineering needs.
2. The top slides can be individually operated with power to skillfully cut short taper surfaces, offering remarkable flexibility and control.
3. Experience automated precision when turning long taper surfaces through the synergistic compound movement,
combining longitudinal feed with the top slide feed. Furthermore, the machines excel in operations such as drilling, boring, and trepanning, enhancing your production capabilities.
These functionalities make them indispensable tools for complex machining tasks.
4. Renowned for their power and high spindle speed, these machines are designed with high rigidity to ensure durability and performance in demanding environments.
5. The machines effortlessly handle parts composed of various ferrous and non-ferrous metals, achieving seamless heavy cutting with carbon alloy tools.
They stand as a testament to efficiency and robust engineering.
Product Parameters

SPECIFICATION		Model
		CW611OOD CW621OOD	CW61125D CW62125D	CW61140D CW62140D	CW61160D CW62160D
Max.swing diameter over bed		1000	1250	1400	1600
Max.swing diameter over crossslide		630	880	1030	1030
Max.swing over gap		1450	1700	1850	2050
Width of bed		755mm
Max.length of workpiece		1000 2000 3000 4000 5000 6000 7000 8000 9000 10000
Spindle nose		A15
Sindle bore diameter		130mm
Taper of spindle bore		Metric No.140#
Range of spindle speed		3.15-315r/min 21kinds
Longitudinal feeds range		0.1-12mm/r 56 kinds
Transversal feeds range		0.05-6mm/r 56kinds
Rapid speed	Z-axis	3740mm/min
	X-axis	1870mm/min
	upper toolpost	935mm/min
Metrec thread range		0-120mm 44kinds
Inch thread range		3/8-28 teeth/iuch. 31kinds
Modular thread range		0.5-60mm 45kinds
Pitch thread range		1-56teech/iuch 25kinds
Tailstock sleeve taper		Morse NO.6
Tailstock sleeve diameter		140mm
Tailstock sleeve travel		300mm
Main motor power		22kW
Rapid motor power		1.5kW
Coolant pump power		0.125kW

Stand Accessories
1. Four-jaw chuck Φ 1000mm: A vital accessory providing stability and precision for your machining tasks.
2. Steady rest Φ70--480mm: Ensures secure support for intricate machining operations.
3. Follow rest Φ50--220mm: Enhances accuracy and reliability in turning operations.
4. Dead center MT No.6: Critical for maintaining alignment and stability during operations.
5. Revolving center MT No.6: Facilitates smooth and continuous rotation, ensuring flawless outcomes.
6. Light: Illuminate your workspace for enhanced visibility and precision.
7. Coolant pump: Maintain optimal temperatures to prolong tool life and ensure impeccable results.
8. Tools: Tailored instruments for a wide range of machining tasks, enhancing productivity and performance.
Special Accessories, Extra cost
1. Four-jaw chuck Φ 1250mm: Accommodates larger workpieces, expanding your machining capabilities.
2. Steady rest Φ 400--700mm/Φ700--1000mm (for CW61140D, CW61160D only): Provides additional support for larger components, essential for heavy-duty tasks.
3. Thread chasing dial device: Facilitates precision threading operations, ensuring consistent results.
4. Taper turning attachment: Enables precise taper turning, enhancing operational versatility.
5. Digital readout: Offers real-time data display, optimizing accuracy and efficiency.
