Rust Resistant Ratchet Lever Hoist for Outdoor Harsh Environments

Product Description

Product Description
0.25T-9T Hand Plate Gourd Manual lever chain hoist features a rugged steel frame, load chain hardened for strength and durability and compact design that's perfect for tight spaces. Enclosed gear housing provides protection that makes it suitable for outdoor use. Guide slots guard against jamming and slipping.Detail
Strong portability: small size, light weight, easy to carry and transfer between different work sites, suitable for mobility operations.
Easy operation: by hand to pull the handle drive, no external power or complex power source, simple operation method, personnel can get started with simple training.
Wide range of application: it can be used in narrow space and no power supply, and can be lifted vertically, pulled horizontally or tilted to pull heavy objects.
Compact and stable structure: reasonable component layout, strong shell, can withstand large tension and pressure, ensure the stability of operation, reduce the risk of failure caused by structural problems.
High transmission efficiency: The internal gear and other transmission components are designed accurately, which can effectively convert manpower into lifting force, save effort during operation, and lift heavy objects more easily.
Reliable braking: With a reliable braking system, it can brake quickly when it stops pulling the handle, so that the heavy object can stay firmly in the corresponding position, prevent sliding, and ensure the safety of operation.
Strong adaptability: reasonable shape and size design, can adapt to a variety of specifications of the sling, a wide range of applications.
Flexible rotation: the connecting part of the hook and the main body of the hoist can be rotated flexibly, which is convenient for lifting operation at different angles and improves the convenience of use.

HSH-V LEVER BLOCKS
Model	HSH-V2.5	HSH-V5	HSH-V7.5	HSH-V10	HSH-V15	HSH-V20	HSH-V30	HSH-V60	HSH-V90
Rated load (T)	0.25	0.5	0.75	1	1.5	2	3	6	9
Test load(T)	0.375	0.75	1.125	1.5	2.25	3	4.5	9	13.5
Standard lif(m)	1	1.5	1.5	1.5	1.5	1.5	1.5	1.5	1.5
Min.distance between two hooks(mm)	205	260	295	295	335	385	450	615	720
Efforts required at capacity (N)	217	303	140	185	234	251	363	370	375
No.of load chains	1	1	1	1	1	1	1	2	3
Dlameter of load chain(mm)	4	5	6	6	7.1	8	10	10	10
Dimensions(mm) A B C D E	92 75 205 153 17	110 82 260 261 23	152 128 295 256 26	152 128 295 256 26	175 148 335 368 30	175 160 385 368 33	195 181 450 368 34	195 232 615 368 47	195 366 720 368 64
Net weight(kg)	1.85	4.6	7.7	8	10.6	14.8	20	28	46

Main Product
Company Profile
Established in 1986, Changshu Seagull Crane&Hoist Machinery Co., Ltd. is a leading manu-facturer of lifting tools and equipments, including hand chain hoists, lever hoists, electric hoists, lifting clamps and more. With ISO9001:2015certification and TUV CE/GS approvals, we ensure top-quality products for global markets like the USA, Germany, Japan, and others. As a trusted OEM partner for international brands, we export 95% of our products worldwide. Our advanced testing facilities and strict quality control guarantee reliable performance. Over 50% of our clients have collaborated with us for more than 10 years, thanks to our consistent quality and excellent service.
SEAGULL is your reliable partner for innovative lifting solutions.
Our Advantages
Certificate&Exhibition
Packaging & Shipping
FAQ
About US
Q1 Manufacturer or Trading Company?
We are Manufacturer and trading company, based in ChangshuCity,Jiangsu Province. Focus: high-quality, safe lifting solutions.
Q2 Certifications?
ISO9001, CE, GS, ASME compliant. Certificates available upon request.
Q3 OEM/ODM?
Yes. Custom colors, logos, manuals,packaging.
Q4 Advantages?
Quality products, wide range, customization, competitive pricing, excellent after-sales service.
Products
Q1 Main Products?
Manual Chain Hoists, Electric Hoists, Electric Trolleys, Beam Trolleys, Beam Clamps, Lifting Clamps, Snatch Blocks, Permanent Magnet Lifters, Mechanical Jacks, Manual Winches, Webbing Slings, etc.
Q2 Manual Chain Hoist Capacity?
0.25 tons - 50 tons. Custom options available.
Q3 Chain Material?
High-strength alloy steel, heat-treated, EN818-7 compliant.
Q4 Electric Hoist Voltage/Control?
220V/380V/415V/440V,50Hz/60Hz. Hand & remote control options.
Q5 Choosing the Right Tool?
Consider load, height, environment, frequency, safety. Contact sales for assistance.
Q6 Product Catalog?
Request via contact form.
Orders&Payment
Q1 MOQ?
Varies. Different products with different MOQ. Please contact us for details.
Q2 Payment Methods?
T/T or L/C in USD/RMB/EUR.
Q3 Delivery Time?
30-60 days, but negotiable for urgent order.
Q4 Trade Terms?
FOB, CIF, CFR, negotiable
After-Sales Service
Q1 Warranty?
1 or 2 years warranty depends on different products, against defects (non-human caused).
Q2 After-Sales Support?
Contact sales representative, email
Q3 Technical Support?
Installation, debugging, maintenance assistance available.
Other
Q1 Samples?
Available on request. Fees may apply.
Q2 Become an Agent?
Contact sales team for details.
