Basic Info.
Model NO.
M7130/7140/7150/7163
Type
Surface Grinding Machine
Controlling Mode
Artificial
Automatic Grade
Semiautomatic
Cylindrical Grinder Type
Surface Grinding Machine
Certification
GS, CE, ISO 9001
Worktable Size
320X1000mm
Chuck
Magnetic Chuck Table
Grinding Wheel Size
350X40X127mm
Longitudinal Moving
Hydraulic
Production Capacity
1000/Year
Product Description
Product Description
Wheel head moving surface grinder Features:This versatile surface grinder is expertly crafted for optimal performance in the machine manufacturing industry, making it the ideal choice for grinding steel, castings, and non-ferrous components, offering unmatched precision and reliability.The machine's precision engineering meets the rigorous National Standard, ensuring exceptional accuracy for horizontal spindle & rectangular worktable surface grinders, elevating your machining capabilities.Experience seamless operation with the worktable's longitudinal movement, powered by a vane pump that guarantees smooth transitions and minimal noise, enhancing your workflow efficiency.Engineered for robustness, the wheel head spindle features bimetal shell bearings capable of withstanding heavy impacts, enabling the machine to tackle heavy-duty grinding tasks with ease and precision.Enjoy effortless operation with the wheel head's cross movement, which can be controlled manually or automatically via hydraulic oil. The vertical feed is hand-driven but equipped with a rapid elevating motor, reducing labor intensity and boosting operational efficiency.Renowned for its smooth motion and dependable performance, this machine operates quietly, maintains stable accuracy, and is user-friendly, earning it widespread acclaim from our customers.
Product Parameters
Model | Unit | M7130 | M7140A | M7140A | M7140A | M7150A | M7150A | M7150A | M7163 | M7163 | M7163 |
x1600 | x2200 | x1000 | x1600 | x2200 | x1250 | x1600 | x2200 |
Worktable size(WxL) | Mm | 300x1000 | 400x1000 | 400x1600 | 400x2200 | 500x1000 | 500x1600 | 500x2200 | 630x1250 | 630x1600 | 630x2200 |
Max matching dimension(W x L) | Mm | 300x1000 | 400x1000 | 400x1600 | 400x2200 | 500x1000 | 500x1600 | 500x2200 | 630x1250 | 630x1600 | 630x2200 |
Max distance between spindle center | Mm | 575 | 600 | 700 |
lineand worktable surface |
Longitudinal moving speed of worktable | m/min | 5//25 | 3//27 |
T-slot number x W | Mm | 3x18 | 3x22 |
Wheel head | Continuous | m/min | 0.5-4.5 |
feed speed |
Cross moving | Intermittent | Mm/t | 3//30 |
feed speed |
| Hand wheel | Mm/gra | ------ | 0.02 | 0.01 |
feed |
Vertical | Rapid | Mm/min | | 400 |
Moving | speed |
of wheel head | Hand wheel | Mm/.gra | 0.005 |
feed |
Wheel Head | Power | Kw | 5.5 | 7.5 | 7.5 |
motor | Rotation | Rpm | 1440 |
speed |
Total power | Kw | 8.63 | 11 | 13.5 | 12.25 | 13.75 | 15.75 | 13.75 | 15.75 |
Max loading capacity | Kg | 470 | 620 | 1000 | 1380 | 700 | 1240 | 1410 | 1010 | 1290 | 1780 |
of worktable |
(with chuck) |
Chuck size(WxL) | Mm | 300x680 | 400x1000 | 400x800 | 400x1000 | 500x1000 | 500x800 | 500x1000 | 630x1250 | 630x800 | 630x1000 |
x1 | x1 | x2 | x2 | x1 | x2 | x2 | x1 | x2 | x2 |
Wheel size | Mm | 350x40 | 400x40 | 400x40x203 |
(ODxWxID) | x127 | x127 |
Machine | Cm | 286x154 | 311x182 | 494x182 | 674x182 | 311x190 | 514x190 | 674x190 | 399x220 | 514x220 | 674x220 |
dimension(LxWxH) | x203 | x223 | x223 | x223 | x242 | x242 | x242 | x242 | x242 | x242 |
Machine Weight | t | 3.49 | 5.01 | 6.51 | 7.6 | 5.78 | 7.32 | 8.78 | 6.86 | 7.85 | 9.65 |
