Cycjet Lf30f Online CO2 Engraving Machine for Glass Bottles

Cycjet Lf30f Online CO2 Engraving Machine for Glass Bottles

US$8,500.00
1-4 Sets
US$8,200.00
5+ Sets

Basic Info.

Model NO.
LC30F
Cooling System
Air Cooling
Technical Class
Pulse Laser
Laser Wavelength
CO2 Laser
Laser Classification
Gaseous Laser
Type
CO2 Laser Marking Machine
Marking Method
Scanning Marking
Name
High Efficiency CO2 Laser Printer for Cocktail Bot
Appications
Glass Bottle
Capacity
10/20/30/50W
System Language
English
Operation
Touch Screen
Marking Range
110 mm X 110 mm
Laser Device
Fiber
Transport Package
Wooden Case with Foam
Specification
150cm X 55cm X 90cm
Trademark
CYCJET
Origin
Shanghai
HS Code
8456100090
Production Capacity
300units/Month

Product Description

Product Picture:
Components of Machine:
Applications:
This type laser marking machine was designed for all kind of bottles, such as glass, plastic bottle. Also suitable for other materials, paper, rubber etc. It could print code and information on the glass bottle when the conveyor belt running. The code can not remove and erase. The most important is laser marking machine do not need any consuner materials, less mechanical failure. It save the factory lot of production cost in future.
Also suitable for electronic components, electrical products, IT industry, auto parts, hardware tools products, precision instruments, gift accessories, medical equipment and other high-end products of precision, fine logo printing. Typical applications such as, plastic (PA66) insulation flying laser marking, metal plate laser marking, packing box body online laser marking, etc.
Advantage:
1, Perfect design software, easy to learn and operation
2, Less Mechanical Faliure
3, Operation Status: Fly and Standstill
4, The code can not move or erase it
5, No consumer goods, less production cost
Terms Of Payment:
T/T, LC
After-sale Service:
1, Warranty Valid: 12 Month
2, Online or Spot Training
Details and Specifications:
PERFORMANCE Frame Material ALUM.
Laser Device CO2 Laser Device
Power ≥30W
Laser Wavelength 10.64um
Galvanometer
deflection
High Precision dual dimensional scanning system
Marking speed ≤12000mm/s
Master Control Highly integrated board with 10 inch Color Touch screen
Operating System LINUX based with High Speed Pipe Marking Software
Cooling 3 groups Cooling Fans
Marking Specifications Focus Distance Focus 140mm
Marking line type Dot matrix, bold, vector all in one(both dot matrix and vector)
Minimum line width 0.04mm
Repeatability accurate
positioning
0.01mm
Marking Area Standard 110mm×110mm(Customized available)
Marking height Standard Character height 110mm
Marking Length Unlimited
Positioning mode Red light positioning and focusing
Number of characters Any line(multi-line) within marking range
Line Speed Standard 0~120m/min (depends on material &text)
Support type Typeface Chinese , English, available to customized
Marking Number, logo, image, letter, serials number, system date & time,etc...
File format CNF/PLT
Bar code CODE39,CODE128,CODE126,QR,Z-Code
Others Power Supply 100-220V/50-60HZ
Power Consumption 600W
Net Weight 68kg
Oversize 150cm X 55cm X 90cm
Environmental Requirement 0ºC-45ºC; humidity≤95%; non-condensing; no shaking
The Quality Standard of CYCJET CO2 Laser Marking Machine
GB 7247-87 Radiation safety of laser products, requirements for equipment classification and user's Guide
GB10320-88 Electrical safety of laser equipment and facilities
ISO 9000-3 International software standards
GB/T12123-89 Sales packaging process
IEC 536 Classification of electrical and electronic equipment for protection against electric shock
