High Precision Surface Grinding Machine (SG50100AHR SG50160AHD SG60120AHR SG60220AHD)
| US$20,000.00-30,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
SG50100AHR SG50160AHD SG60120AHR SG60220AHD
Abrasives
Grinding Wheel
Controlling Mode
Hydraulic
Automatic Grade
Semiautomatic
Cylindrical Grinder Type
Surface Grinder
Precision
Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Table Size
500X1000mm
magnetic chuck
500X1000X1
grinding wheel speed
1450rpm
AUTO FEED(wheelhead)
0.5-20
WHEEL SIZE
355X50X127mm
Transport Package
Plywood Case
Specification
5500kgs
Trademark
HOTON
Origin
Shandong, China
HS Code
8460190000
Production Capacity
10 PCS/Month
Product Description
SURFACE GRINDER FEATURES:
Headstock runs in preloaded angular ball bearings and features a high load capacity
X and Y axis guide ways are counter-laminated(plastic)
Separate hydraulic unit with oil cool
X axis with high-dynamic, hydraulic drive
Combination of box ways and V-guides on X and Y, plus rectangular guide way on Z
Premium components ensure maximum accuracy for continuous operation
SPECIFICATIONS:
| SPECIFICATION | UNIT | SG50100 AHR/AHD | SG50160 AHR/AHD | SG60120 AHR/AHD | SG60160 AHR/AHD | SG60220 AHR/AHD | |
| Table size | mm | 500x1000 | 500x1600 | 610x1200 | 610x1600 | 610x2200 | |
| Max. grinding (WxL) | mm | 500x1000 | 500x1600 | 610x1200 | 610x1600 | 610x2200 | |
| Max. distance from table to spindle center | mm | 600 | |||||
| Magnetic chuck size (optional equipment) | mm | 500x1000x1 500x800x2 600x1000x1 600x800x2 600x1000x2 | |||||
| Speed of table longitudinal movement | m/min | 5-25 | |||||
| Wheelhead cross movement | Auto feed | mm/t | 0.5-20 | ||||
| Rapid speed | m/min | 1.25 | |||||
| Feed of handwheel | mm/div | 0.02 | |||||
| Wheelhead vertical movement | Auto feed | mm/t | 0.005, 0.01, 0.015, 0.02, 0.03, 0.04 (only for AHD model) | ||||
| Rapid speed | mm/min | 230 | |||||
| Feed of handwheel | 0.002 | ||||||
| Wheel | Speed | Rpm | 1450 (50HZ), 1740 (60HZ) | ||||
| Size (ODxWxID) | mm | 355x (20-50) x127 | |||||
| Motor of spindle | kw | 7.5 | |||||
| Max. loading capacity of table (include chuck) | kg | 700 | 880 | 970 | 1230 | 1690 | |
| Total rated power | kw | 12 | 14 | ||||
| Height of machine | mm | 2390 (include the packing base) | |||||
| Floor space (LxW) | mm | 4700x2550 | 7120x2550 | 4740x2750 | 5340x2750 | 6740x2750 | |
| Gross weight | kg | 5500 | 6000 | 6500 | 7000 | 8000 | |
| Contact Us: |
Andy Wang TENGZHOU HOTON MACHINERY CO.,LTD Tel:0086 632 5633796 MP:0086 13506328892 hotonmachinery.en.made-in-china.com |
| Company Profile: |
| Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008. |
| The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale. |
| Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills. |
