High Performance Rectangle Stepped Permanent Magnet T-Shaped Magnet

Product Description

Product Description:
High performance rectangle stepped permanent magnet T-shaped magnet
This T shaped /Stepped shaped provides a perfect solution to fix magnets on other components. For example, T shaped custom made magnet can be suitable for injection over mold with the prominent part. Besides, this irregular shape is quite easy to produce compared with other complex shapes. Multimagnets can produce other shapped magnets, welcome to contact us for more details.
Magnet Material: Neodymium (NdFeB) magnet
Grade: N35 -N54
Size: T shaped magnet
Magnet shape: ring, disc, block, arc or other custom shape
Coating/ Surface: NiCUNI, EPOXY, CHROME etc.
Standard Tolerance: +/-0.05mm
Magnetization direction: Axial /Thickness
Magnetic strength:2000-8000Gs
Salt spray test standard: 48 hours / 96 hours
Certification: Rohs, Reach, ISO9001, MSDS.

Product name	High performance rectangle stepped permanent magnet T-shaped magnet
Grade	N35-N55
Coating	Nickel, Zinc, Gold, Cr, Black epoxy
Tolerance	+/-0.05mm
Application	Industrial magnet, motor magnet, speaker magnet

Neodymium magnets also called Neodymium iron boron (NdFeB), which offer the highest energy product of any material today and are available in a wide range of shapes, sizes and grades.
Application of neodymium magnet: Neodymium magnet (also known as NdFeB or Neo magnet) is the most widely used type of rare-earth magnet which is made from an alloy of neodymium, iron, and boron. Neodymium magnets are widely used in automotive industry, hardware accessories, motors, cameras, clean energy, electronics, sound device, home & office use, health care, separation filtration equipment, and various fields of daily life.
How to separate strong magnet: 1. Slide one magnet off the top of the stack
2. Lift and tilt the top magnet away
3. Lift the magnet to free it from the stack
How to restore to their original: If you need to put the magnet back into the whole magnet, please put it back slowly, starting from the edge at a close distance. Be sure to hold the magnet with your hand until the magnet has moved in. Do not attract the magnet directly from a distance, otherwise the product will break, or the fragments will hurt people.
Standard package of magnet by air: If magnet shipped by air, there is a kit of iron sheet inside of carton to shield the magnetism.
Standard package of magnet by sea or by train: If magnet shipped by sea or by train, there is no iron sheet inside of carton. It could be exported as general cargo.
Warning: The magnet has strong magnetism. Keep out of reach of children under 16. SWALLOWING IS STRICTLY PROHIBITED!
How to promise the quality: Quality is our culture! To ensure our quality, all magnets are produced with 100% new standard material rather than recycle or bad material. Besides our professional QC department will inspect the magnet for each stage, including magnet grade, coating, dimension, tolerance and pulling force for pot magnet, magnetic hook, fishing magnet or other magnetic assemblies. So that our magnet pass rate is as high as 99.5%.
Following is the production processes of neodymium magnet from raw material to finished product.
Magnetism direction for neodymium magnets with different shapes:
Our package & shipment for neodymium magnets:
Multimagnets manufacturers quality Neodymium magnets in sizes and shapes. Custom service is our advantage, please contact us for further information of our neodymium magnets, all grades and shapes are available to provide for us.
As always, if you are doubtful about magnets, we are happy to send samples to test the magnets in your own auspices and environment.
