Multi-Function Vertical Drilling Machine Z5032c Z5040c Z5045c
| US$2,500.00-4,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
Z5032C Z5040C Z5045C
Structure
Vertical Drilling Machine
Layout
Vertical
Controlling Mode
Artificial
Number of Shaft
0
Hole Diameter
151-200mm
Automatic Grade
Automatic
Precision
Precision
Certification
CE, ISO 9001, CE, ISO 9001
Condition
New, New
Application
Metal
Movement Method
Point to Point Control
After-Sales Service
Online Support
Process Usage
Metal Drilling Taping
Control Method
Manual
Numerical Control
Manual
Processing Precision
Without
Performance Classification
Metal
Max. Driiling Capacity
32mm
Max. Taping Capacity
Mt3
Max.Spindel Travel
130mm
Spindel Speed
80-1250rpm
Motor Power
0.75kw
Transport Package
Plywood Case
Specification
Cast Iron
Trademark
HOYONG-TRD
Origin
Shandong, China
HS Code
845929000
Production Capacity
300
Product Description
VERTICAL DRILLING MILLING MACHINE
Compound sliding table with scale and adjustable stops for coordinate drilling and light milling work
Quiet operation with oil-bath lubricated gears for long tool life and durability
The milling machine's high-quality spindle bearing can withstand higher loads for the long term
Manual drill feed can be switched to high-precision feed via a hand-wheel
Controllable automatic feed with 3 gear steps
Adjustable height of gear head and table
Table guides are adjustable with high precision via taper gibs
Gear head swivels to both sides
Cutter mounts are secured by an M16 draw bar
Tapping feature
Integrated coolant system
SPECIFICATIONS:
| ITEM | Z5032C | Z5040C | Z5045C |
| Max.drilling capacity | 32mm | 40mm | 45mm |
| Spindle taper | M.T.3 or R8 | M.T.4 | M.T.4 |
| Spindle travel | 130mm | 130mm | 130mm |
| Step of spindle speed | 6 | 6 | 6 |
| Range of spindle speed 50Hz | 80-1250 r.p.m | 80-1250 r.p.m | 80-1250 r.p.m |
| 60Hz | 95-1500 r.p.m | 95-1500 r.p.m | 95-1500 r.p.m |
| Min.distance from spindle axis to column | 283mm | 283mm | 283mm |
| Max.distance from spindle nose to worktable | 700mm | 700mm | 700mm |
| Max.distance from spindle nose to stand table | 1125mm | 1125mm | 1125mm |
| Max.travel of headstock | 250mm | 250mm | 250mm |
| Swivel angle of headstock (horizontal /perpendicular) | 360°/±90° | 360°/±90° | 360°/±90° |
| Max.travel of worktable bracket | 600mm | 600mm | 600mm |
| Table size | 730×210mm | 730×210mm | 730×210mm |
| Size of stand worktable of available | 417×416mm | 417×416mm | 417×416mm |
| Forward and afterward travel of worktable | 205mm | 205mm | 205mm |
| Left and right travel of worktable | 500mm | 500mm | 500mm |
| Vertical travel of worktable | 570mm | 570mm | 570mm |
| Motor Power | 0.75kw | 1.1kw | 1.5kw |
| speed of motor | 1400rpm | 1400rpm | 1400rpm |
| Net weight/Gross weight | 430/500kg | 432/502kg | 435/505kg |
| Packing size | 1850x750x 1000mm | 1850x750x 1000mm | 1850x750x 1000mm |
