Customized Industrial 500g-5000g Small Mini Portable Hydraulic Electric Cargo Goods Elevator Shaft Lift for Warehouse Maintenance
| US$800.00-1,500.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
HT
Lift Mechanism
Lift Chain
Deceleration Device
Without Deceleration Device
Guide Rail
Groove Guide
Attendant
Without Attendant
Loading Capacity
500g-5000g
Voltage
380V
Application
Workshop Crane, Shipboard Crane, Warehouse Crane,
Transport Package
Wooden Case
Specification
2000X2000mm or Customized
Trademark
HONFU
Origin
Shandong Province, China
HS Code
8428909090
Production Capacity
10000 Units/Year
Packaging & Delivery
Package Size
200.00cm * 150.00cm * 200.00cm
Package Gross Weight
1000.000kg
Product Description
Product DescriptionCargo elevator is a kind of lifting equipment used for cargo transportation, mainly used to solve the problem of cargo transportation in the vertical direction, widely used in commercial, warehousing, logistics and other industries. Technical Parameters
| Specification | Liting height (mm) | Lowered height (mm) | Capacity (Kg) | Platform size (L*W, mm) | Power (Kw) |
| HT0.3-4.5 (2 floor) | 4500 | 150 | 300 | 1000x800 | 1.5 |
| HT0.5-4.5 (2 floor) | 4500 | 150 | 500 | 1500x1000 | 1.5 |
| HT1.0-4.5 (2 floor) | 4500 | 150 | 1000 | 1500x1500 | 2.2 |
| HT2.0-4.5 (2 floor) | 4500 | 150 | 2000 | 2000x1000 | 2.2 |
| HT3.0-4.5 (2 floor) | 4500 | 150 | 3000 | 2000x1200 | 3.0 |
| HTE0.3-7.5 (3 floor) | 7500 | 150 | 300 | 1000x1000 | 1.5 |
| HTE0.5-7.5 (3 floor) | 7500 | 150 | 500 | 1200x1200 | 1.5 |
| HTE1.0-7.5 (3 floor) | 7500 | 150 | 1000 | 1800x1400 | 2.2 |
| HTE2.0-7.5 (3 floor) | 7500 | 150 | 2000 | 2000x1500 | 2.2 |
| HTE03.0-7.5 (3 floor) | 7500 | 150 | 3000 | 2000x1600 | 3.0 |
| HTE1.0-10.5 (4 floor) | 10500 | 150 | 1000 | 1800x1400 | 3.0 |
| HTE1.0-14 (5 floor) | 14000 | 150 | 1000 | 1800x1500 | 4.0 |
| HTE03.0-4.5 (car lifting) | 4500 | 150 | 3000 | 6000x3000 | 4.0 |
Product Show Company Profile
