Ram type sawdust briquette equipment

Product Description

Product Description
Product Description Ram type sawdust briquette equipmentRam type sawdust briquette equipment is a die and ram type mechanical press with two flywheels. Each flywheel is driven by belts with motors. Material is continuously fed through a hopper by belt conveyor with its own gearbox and a motor. From feeding chamber, raw material is compressed by ram through taper bore die. Briquettes comes out from cooling track. Total process is continuous and controlled by electric panel. Briquetting press is used for producing high density fuel briquettesDetailed ImagesHydraulic sawdust briquetting press equipment include1.Screw conveyor2.Feeding hopper3.Main press equipment4.Control cabinet5.Oil cooling equipment6.Output line Specifications Model YKB20A Length of Raw material ≤3 mm Power 75KW Moisture content of raw material From 10% to 13% Capacity 1500 kg/h Density of the finished product 1.1-1.3g/cm3 Diamession 1800*3800*1700mm Shape of the finished product cylinder-shaped Weight 8000kg Heating value 3700-5000kcalRaw Material and finshed product Index Of Briquette1.Density of briquette :1.1-1.3g/cm3 2.Heating value :3700-5000kcal3.Sulfur dioxide emissions: 0.38% 4.Carbon dioxide emissions: 0.22%5.Ash content 3.6%, and the ash could be recycled as agricultural potash, which can realize green recycling. Our CustomersYUKE products have been a nation wide hot sale ,and exported to various countries and regions aroubd the world such as India ,Malaysia,Vietnam,Philippines,Indonesia,Thailand ,Russia,Africa,South America,Europe,etc.In the industry ,our products have won great popularity and recognition among users.Our ServicePre-Sales Service* Inquiry and consulting support. * Sample testing support. * View our Factory.After-Sales Service* Training how to install the machine, training how to use the machine. *Readily available spare parts.*Our engineers can provide service overseas..Certifications
