Stavol AVR 5000W Color Display Digital Full Range Automatic Voltage Stabilizer
Basic Info.
Model NO.
ST-5000VA
Frequency Characteristics
Low Frequency
Usage
SVC
Frequency
Low Frequency
Size
Small
Iron Core Shape
Ring
Power Source
Linear Regulated Power Supply
Application Range
Home Appliances
Brand
Voltlook
Input Voltage Range
140-250V; 100-250V
Output Voltage
220V, 230V or 220V+110V
Rated Power
4000W
Display
LCD
Transformer Material
Copper
Regulating Precision
3%
Transport Package
Color Box and Master Carton
Specification
5000VA
Trademark
VOLTLOOK
Origin
China
HS Code
8504401500
Production Capacity
500, 000pieces/Year
Product Description
ST and SVC-D Series Single Phase Servo Motor AC. Automatic Voltage Regulator with LCD Display
Features:
+ Single phase servo motor control
+ High precision regulation output
+ Pure copper winding coil, variable transformer an buck-boost transformer
+ Analog meter display
+ Fully automatic MCU controlled circuit
+ Available power capacity from 0.5KVA to 30KVA
+ Full protection: over voltage, under voltage, overheat, overload, sag, surge, spike and short circuit
+ Delay Time to protect the equipment from rapid fluctuations
+ CE certified
Specifications
| Model | SVC-500VA | SVC-1000VA | SVC-1500VA | SVC-2000VA | SVC-3000VA | SVC-5000VA | SVC-7500VA | SVC-10KVA | SVC-15KVA | SVC-20KVA | SVC-30KVA | |
| Power | 500VA | 1000VA | 1500VA | 2000VA | 3000VA | 5000VA | 7500VA | 10000VA | 15000VA | 20000VA | 30000VA | |
| Technology | Fully automatic MCU controlled circuit + toroidal transformer | |||||||||||
| Transformer | Copper Servo Motor Type Transformer | |||||||||||
| Input | Input voltage range | 150-250V AC / 100-250V AC | ||||||||||
| Input frequency | 50Hz | |||||||||||
| Output | Output voltage | 220V AC / 220V+110V | ||||||||||
| Output precision | ± 3% | |||||||||||
| Delay Time | 6s /180s selectable | |||||||||||
| Efficiency | ≥95% | |||||||||||
| Phase | Single phase | |||||||||||
| Display | Analog meter | Input voltage & Output voltage separately | ||||||||||
| LED indicators | Green LED | Indicating power ON/OFF | ||||||||||
| Yellow LED | During delay,this LED flashes,delay finished,goes off | |||||||||||
| Red LED | Output suppressed, indicating the machine is executing protection,when protection finished,goes off | |||||||||||
| Protection | High voltage | Output cutoff + red LED | ||||||||||
| Low voltage | Output cutoff + red LED | |||||||||||
| Over load | Output cutoff | |||||||||||
| High temperature | Output cutoff | |||||||||||
| Short circuit | Circuit breaker trip off | |||||||||||
| Cooling system | Air Cooled | Smart Fan (Automatic Startup at 65°C) | ||||||||||
| Safety standards | CE (LVD + EMC) , EN60950, EN55024 | |||||||||||
| Operating conditions | Operating temperature | -5ºC - 45ºC | ||||||||||
| Stroage temperature | -15ºC - 45ºC | |||||||||||
| Operating relative humidity | 10%RH - 90%RH, Non-condensing | |||||||||||
+ Refrigeration equipments: fan, refrigerator, chest freezer, cooler and air conditioner
+ Kitchen appliances: microwave oven, rice cooker
+ Entertainment appliances: TV, DVD, VCR, DVB, HiFi
+ IT & Office equipments: PC, workstation, fax machine, photocopier
+ Heating systems: gas boiler, circulation pump
