Automatic Spiral Cardboard Paper Core & Tube Machine

Product Description

Automatic Spiral Cardboard Paper Core & Tube Machine Product Description Usage
Common model, it is used for making tubes for all kind of tape, jumbo roll, chemical fiber, paper cans, etc.
Feature
Cheaper price, high popularity, high performance. Adopted PLC logic control system. Main motor is adopt vector type of high torque inverter for speed regulate Positioning length by photo electricity with auto speed changing function, in order to meet high cutting precision. Modern electric layout designing for easy and science using, maintaining and repairing. There is a remote controller for easy operating(to stop or slow down the machine when lacked paper) Low noise driving designing. Adopt double size gluing and independent stainless steel gluing box, with imported silicone tube Detailed Photos


Product Parameters

Machine Detail
paper layer	2-7layers
inner diameter	15-60(mm)
thickness	1-5(mm)
speed	0-45(m/min)
Fixed length mode	light control
Winding head	Two head
Cutting method	Circular knife CNC automatic
Gluing method	Double-sided glue
way to control	Frequency
Input voltage	380V/220V
Number of operators	1-3
total weight	1900kg
Main engine power	2*3.7kw
PLC controller	Special products
HMI	Special products
Frequency converter	ENERGY
Electrical components	Omron/Chint
Signal element	Omron/Pefun
Button/emergency stop	Siemens
Pneumatic Components	Airtac/Tianao
Host size:	4300*1500mm*1800mm
Area size:	11000mm*5000mm
Upper paper shelf	Right-angle belt hoisting
Glue frame	Automatic gluing
Bottom paper break	Automatic alarm
Bottom surface paper	stainless steel pot device
Paper guide wheel	stainless steel pipe
Host table	Stainless steel plate
Mandrel	1
Tube belt	1 pieces
Unloading rack	Stainless steel automatic
application tools	1 set

Certifications
Packaging & Shipping
Company Profile
FAQ
FAQ:
1.How to install and maintain the machine?d
Firstly, we will provide the installation guild with the machine for your reference.
Secondly, our company is responsible for training production workers for you, ensuring that the workers will be independent operation.
2.How can we get the matching accessories or wearing parts conveniently?
During the warranty, Our company can replace the accessories for free .Out of warranty,we can provide them at the preferable price. In fact, the wearing parts are standard parts that you could get it in your country at your convenience.
