T4 Stainless Steel Foodstuff Tank Container Petroleum ISO Tank

Product Description

Product Description
Specification Tank Type: 20' ISO full frame collar tank, Type UN Portable Tank T4 Frame Dimensions: 20' x 8' x 8'6" Capacity: 26,000 Litres +0 /- 1% M.G.W.: 36,000 kg Working Pressure: 1.76 Bar Test Pressure: 2.65 Bar Max. Allowable Vacuum: 0.41 Bar Design Temp: -40ºC to +100ºC Vessel Material: ASTM A240 304 hot rolled or equivalent Shell Thickness: 5 mm nominal Ends Thickness 6 mm before forming Corrosion Allowance: 0.2 mm Main Frame Material: GB/T 1591-Q345D Frame to Shell: 304 stainless steel Corner castings: ISO 1161 - 8 off Vessel Design Code: ASME VIII Div 1 Radiography: Shell: ASME Spot Ends: ASME Full Inspection Agency: LR or BV Cargo carried: Food stuff Stacking: Each container is approved for 10 high stacking Design Approvals: IMDG T4, CFR 49, ADR/RID, CSC, TC, TIR, ISO, UIC, US DOT
Packing & Delivery
Company Profile
Our company is one of main factory in China Chemical Equipment Group, and as well as the biggest pressure vessel manufacturer in Zhejiang. Sep. Established in 1972 years, We're engaged in design and manufacture pressure vessel for more than 40 years, and have the Design License of Special Equipment (Pressure vessels of type) (RSPZJHG0401-2), It has the following licenses issued by the State Administration of Quality Supervision, Inspection and Quarantine: A1, A2, B3, C2 and C3 pressure vessel manufacturinglicenses; the design license for A1, A2, C2 and C3 pressure vessels; and the design license of GC1(3), GC2 and GC3 pressure piping .
5m3,10m3,15m3,20m3, 30m3,40m3, 45m3,52m3 LNG/LO2/LN2/LAR/LCO2/T4 ISO Container Tank, diesel ISO tank,Cryogenic Tank , Microbulk tank, and SEMI trailer , We have passed ASME/EN/CCS/ ISO1161/688 /ISO149613 International Quality Supervision System Certification. We own 170000 square meter building size The total assets is 180 million, has 500 workers and staff members, including 55 technician (6 super- engineer, 19 engineer, 10 primary technician, 1 super-technician, 4 technician, 15 Nondestructive Tester (RT, UT). There're 8 departments, such as technology, production, sales, quality, purchase, finance, secretary and standard, 1general management office, 1 international export office (Ningbo DSW), 5 workshops and 1 Installation Company. Set up the Welding Test station with Ningbo Bureau of Quality and Technical Supervision. Quality Guarantee System charged by quality engineer, design engineer, welding.
FAQ
Q1: If you are factory or trade company?
We are manufacturer with more than 20 years.
Q2: What is your delivery time?
We promise 20-25 days once deposit paid and workshop drawings confirmed.
Q3: What is your payment terms?
We accept TT and L/C at sight.
Q4: What is your packing for all tanks?
We can pack all tanks by pallet , also no pallet is available for different type tank.
Q5: Can you provide OEM design?
Yes, we can, we are factory under ourself R&D team, so custom container is welcome.
and we can make customerbrand name on tank shoulder, color, printing, etc...
Q6: What is your MOQ?
Our MOQ is 1 pcs.
Q7: Do you have any protection for the head of the tank?
Yes, in our factory, each cylinder is protected by standard cap which can make sure the safety
of torch during the transportation.
Q8: What is your advantage with other competitors?
We are factory with excellent equipment and high quality control system, and our factory price is more competitive, fast
shipment with high quality, our service is also best with 24 hours on line for fast reply your requestments.
