Chinese New Mini Crawler Digger Excavator Machine Mini Bagger CE EUR EPA Engine 1t/2t/2.5t/3.5t Mini Excavator
| US$12,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
FTE20
Usage
GM Excavator
Bucket
Shovel
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.025~0.06
Size
Small-Scale
Certification
CE, EPA
Condition
New
Operating Weight
1600kg
Engine Power
16.5kw/2200r.p.m
Standard Bucket Capacity
0.06m 3
Maximum Digging Depth
2042mm
Maximum Digging Height
3129mm
Maximum Digging Radius
3737mm
Swing Speed of Frame
8.5 r.p.m
Transport Package
Export Package
Specification
with CE Approval
Trademark
FOTMA
Origin
China
HS Code
84295900
Production Capacity
10000 PCS/Year
Product Description
Chinese New Mini Crawler Digger Excavator Machine Mini bagger CE EUR EPA Engine 1T/2T/2.5T/3.5T Mini ExcavatorIntroduce:
1.The compact excavator has a full open hood, which makes it easy to be repaired and maintenance,saving maintenance time and improves work efficiency. 2.The centralized lubrication is a facilitating for lubracating the slewing bearing and the internal tooth surface of the slewing motor. 3.The hyhdraulic oil level gauge,fuel level gauge,coolant reserve tank,window glass washing liquid tank are arranged in outer lower position for easy observation and to add.
Specification sheet
| Performance | Unit | FTE15 | FTE18 | FTE20 |
| Operating Weight | Kg | 1400 | 1750 | 1950 |
| Engine Model | Kubota D722 | Laidong 3TE25 | ||
| Rated Power | Kw | 10.4KW/2500rpm | 18.4 | 18.4 |
| Bucket Capacity | m3 | 0.025 | 0.06 | 0.06 |
| Bucket Width | mm | 385 | 435 | 435 |
| Max Digging Force | Kn | 9 | 11.5 | 11.5 |
| System Working Pressure | Mpa | 20 | 18 | 18 |
| Swing Speed | rpm | 12~13 | 10~12 | 0~9 |
| Traveling Speed | km/h | 2.1~3.2 | 2.8 | 2.8 |
| Gradeability | 58 | 35 | 35 | |
| Ground Pressure | Kpa | 23 | 38 | 38 |
| Operating Range | ||||
| Max. Digging Distance | mm | 3529 | 3860 | 3860 |
| Max. Digging Depth | mm | 2017 | 2050 | 2050 |
| Max. Digging Height | mm | 2955 | 3370 | 3370 |
| Max. Dumping Height | mm | 2077 | 2390 | 2390 |
| Min. Swing Radius | mm | 1720 | 1720 | 1720 |
| Overall Dimensions | ||||
| Overall Length | mm | 3329 | 3800 | 3800 |
| Overall Width | mm | 990 | 1050 | 1050 |
| Overall Height | mm | 2267 | 2280 | 2280 |
| Min. Ground Clearance | mm | 153 | 210 | 210 |
| Track Ground Length | mm | 1190 | 1050 | 1050 |
| Track Width | mm | 200 | 230 | 230 |
