Band1 LTE 20W Signal RF Power Amplifier Booster Wireless Transceiver Module
Basic Info.
Model NO.
ZLD-PL2140M-43/50N2
Support Network
GSM
Information content
Data
Certification
ISO
Condition
New
Product Name
RF Amplifier Module
Keywords
Jammer Module
Gain
50dB
Power
30W
Supplier Type
OEM/ODM
Warranty
1 Year
Application
Mobile Phone, Repeater
Transport Package
Carton Packaging
Specification
130*110*21mm
Trademark
ZLD
Origin
China
Production Capacity
5000/Year
Product Description
Product Features• LTE 20W RF power amplifier.
• Automatic level/gain control (ALC/AGC), high stability and Reliability.
• Power Amplifier with output short circuit or open circuit protection
• Intelligent monitoring, automatic alarm.
• Small size, light weight, Easy to operate and maintain.
Product Description
• Power amplifier modules are mainly used in mobile communication.
• High efficiency power amplifier module, attached to an aluminum sub carrier.
Electrical Specifications
| Parameter | Specification | |
| Port | Down | UP |
| Frequency Range | 2110~2170MHz | 1920~1980MHz |
| Saturated Output Power | 43±1dBm | -10±1dBm |
| Gain | 50±1dB | 25±1dB |
| Gain Adjustable rang | ≥20dB | ≥20dB |
| Step of Gain Adjustable | ≤1dB | ≤1dB |
| Gain Flatness | ≤2.0dB | ≤2.0dB |
| Noise Figure | / | ≤4.8dB |
| ACPR | -40dBc | -40dBc |
| EVM | ≤5% | ≤5% |
| Out of Band Spurious | 9kHz~1GHz:≤-36dBm/30kHz 1GHz~12.75GHz:≤30dBm/30KHz | |
| Gain Stability | ±1.5dBm | |
| Power stability | ±1.5dBm | |
| VSWR | ≤1.5 | |
| DC Input Voltage | DC28±1.0V | |
| Current Consumption | ≤3.5A | |
| Power and Monitoring port | 5569-06A | |
| Working Temperature | -25ºC~+55ºC | |
| Storage temperature | -40ºC~+65ºC | |
| Impedance | 50Ω | |
| RF connector | SMA and MCX | |
| Monitor inerface | RS-485 | |
| Monitoring communication protocols | Use Manufacturers protocol or Customized | |
| weight | 0.5kg | |
| Dimension | 130×110×21mm | |
| Surface Color | Metal color conductive oxide and other color customized | |
Product Dimensions
