ASTMA312 TP304/316/321 Stainless Steel Cold Rolled Pipe in Zhejiang Factory Price

Product Description

Product Description

Product Name	Stainless Steel Seamless Pipes /Tubes Труба Сталь конструкционная криогенная Tubería de acero inoxidable sin costura Tubos de Aço Inoxidável sem Costura
Company Inform	1.Name:WENZHOU GUOHAO STEEL., LTD 2.Type: Manufacturer
Material	Austenitic: TP304, TP304L, TP304H, TP309S, TP310S, TP316L, TP316Ti, TP317L, TP321, TP321H, TP347H , 904L, 254SMO GOST Grade: 08х18н10т,12х18н10т(AISI 321), 10х17н13м2т(AISI 316Ti), , 20х23н18(AISI 310S), 06хн28мдт(AISI 904L), 08х18н10(AISI304) EN Grade: 1.4301,1.4306,1.4311,1.4541,1.4401,1.4404,1.4550,1.4571,1.4429,1.4435,1.4436,1.4439
	Duplex Stainless: UNS S31803,UNS S2205,UNS S32750, UNS S32760
	Nickel Alloy: Incoloy: 800/800H/800HT 825 926 20 28 201 200 Inconel :718 600 601 625 Hastelloy: C-22 C-276 B-2 B-3 Monel:Monel400,K-500 High-Temperature Alloys:GH3030 Gh3039 Cr20Ni80
Standard	ASTM A312,ASTM A213,ASTM A269,ASTM A511,ASTM A789,ASTM A790 EN 10216-5,DIN 17456 GB/T 14976,GB13296,GB/T21833,GB/T 15011,GB/T 15062 GOST 9940,GOST 9941
Specification	D(Outer Diameter)	6mm-630mm ; 1/8inch-24inch
	T(Wall Thickness)	1mm-40mm ; SCH5S, SCH10S, SCH40S, SCH80S, SCH160, SCHXXS
	L(Length)	Random length 5~7m Fixed length 6m /6.096m /6.1m/12m or as customer's actual request
Surface	Annealing&Pickling Polishing(180#-600#) Bright Annealing Sand Blasting Shot Blasting/Shot Peening
Pipe end	Plain End (PE) Bevel End (BE) Thread End (TE)
Markings	Markings will adhere to prescribed specifications in A999/A999M and shall include the NPS or OD and schedule number or average wall thickness, heat number, and NH (when hydraulic test is not performed) and ET (when eddy-current testing is performed) or UT (when ultrasonic testing is performed). The marking shall also include the manufacturer's private identifying mark, the marking requirement of section 12.3 on Hydraulic or Nondestructive Electric Test, if applicable, and whether seamless (SML), welded (WLD), or heavily cold-worked (HCW). For Grades TP304H, TP316H, TP321H & TP347H, the marking shall also include the heat number and heat-treatment lot identification.
Flattening Test	For material heat treated in a continuous furnace flattening tests shall be made on a sufficient number of pipes to constitute 5% of the lot, but in no case less than 2 lengths of pipe.
Hydraulic Test or Nondestructive Test	Each pipe shall be subjected to the nondestructive test(ET/UT) or the hydraulic test(HT).
Delivery Time	For ready stock :7 days after receiving the deposit of T/T For MTO: 35 days after receiving the deposit of T/T
Trade Terms	EXW,FOB, CFR, CIF etc.
Loading Port	Ningbo/Wenzhou/Shanghai
Remittance method	TT/LC/CASH
Container	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM
Referenced Documents	ASTM Referenced Standards A262 Practices for Detecting Susceptibility to Intergranular Attack in Austenitic Stainless Steels A370 Test Methods and Definitions for Mechanical Testing of Steel Products A941 Terminology Relating to Steel, Stainless Steel, Related Alloys, and Ferroalloys A999/A999M Specification for General Requirements for Alloy and Stainless-Steel Pipes A1016/A1016M Specification for General Requirements for Ferritic Alloy Steel, Austenitic Alloy Steel, and Stainless-Steel Tubes E112 Test Methods for Determining Average Grain Size E381 Method of Macroetch Testing Steel Bars, Billets, Blooms, and Forgings E527 Practice for Numbering Metals and Alloys in the Unified Numbering System (UNS)

Product Parameters
Chemical Composition & Mechanical Perofrmance Austenitic stainless steel and duplex stainless steel pipe

Chemical Composition (%)												Mechanical Performance
Grade	C	Mn	P	S	Si	Cr	Ni	Mo	N	Ti	Others	Mpa (kgf/mm²)		Elongation .(%) em 2" (min.)	Hardness
(AISI)	(max.)	(max.)	(max)	(max.)	(max.)	(min.)	(min.)	(min.)	(min.)	(min.)					HRB
						(max.)	(max.)	(max.)	(max.)	(max.)		Tensile strength (min.)	Yield strength (min.)		(max.)
304	0,080	2,0	0,045	0,030	1,00	18,0	8,0					515	205	35	90
						20,0	11,0
304L	0,035	2,00	0,045	0,030	1,00	18,0	8,0					485	170	35	90
						20,0	13,0
304H	0,040	2,00	0,045	0,030	1,00	18,0	8,0					515	205	35	90
	0,100					20,0	11,0
309S	0,080	2,00	0,045	0,030	1,00	22,0	12,0	0,75				515	205	35	90
						24,0	15,0
310	0,150	2,00	0,045	0,030	1,00	24,0	19,0					515	205	35	90
						26,0	22,0
310S	0,080	2,00	0,045	0,030	1,00	24,0	19,0	0,75				515	205	35	90
						26,0	22,0
310H	0,040	2,00	0,045	0,030	1,00	24,0	19,0					515	205	35	90
	0,100					26,0	22,0
314	0,200	2,00	0,045	0,015	1,50	24,0	19,0		0,11			515	205	35	90
					2,50	26,0	22,0
316	0,080	2,00	0,045	0,030	1,00	16,0	11,0	2,00				515	205	35	90
						18,0	14,0	3,00
316H	0,040	2,00	0,045	0,030	1,00	16,0	11,0	2,00				515	205	35	90
	0,100					18,0	14,0	3,00
316L	0,035	2,00	0,045	0,030	1,00	16,0	10,0	2,00				485	170	35	90
						18,0	14,0	3,00
316Ti	0,080	2,00	0,045	0,030	0,75	16,0	10,0	2,00	0,10 max	5x(C+N)-0,70		515	205	35	90
						18,0	14,0	3,00
317L	0,035	2,00	0,045	0,030	1,00	18,0	11,0	3,00				515	205	35	90
						20,0	15,0	4,00
321	0,080	2,00	0,045	0,030	1,00	17,0	9,0		0,10 max	5x(C+N)-0,70		515	205	35	90
						19,0	12,0
321H	0,040	2,00	0,045	0,030	1,00	17,0	9,0		0,10 max	4x(C+N)-0,70		515	205	30	90
	0,100					19,0	12,0
347	0,080	2,00	0,045	0,030	1,00	17,0	9,0				Nb:10xC-1,00	515	205	35	90
						19,0	13,0
347H	0,040	2,00	0,045	0,030	1,00	17,0	9,0				Nb:8xC-1,00	515	205	35	90
	0,100					19,0	13,0
S31254 254SMO	0,020	1,00	0,030	0,030	0,08	19,50	17,50	6,00	0,18		Cu:0,50-1,00	t≤5mm 675	t≤5mm 315	35	90
						20,50	18,50	6,50	0,25			t>5mm 655	t>5mm 310
904L	0,020	2,00	0,040	0,030	1,00	19,00	23,00	4,00	0,10 max		Cu:1,00-2,00	490	215		90
UNS 8904						23,00	28,00	5,00
UNS31803	0,030	2,00	0,030	0,020	1,00	21,00	4,50	2,50	0,080			620	450	25	HRC 30
						23,00	6,50	3,50	0,20
UNS32205	0,030	2,00	0,030	0,020	1,00	22,00	4,50	3,00	0,14			655	485	25	HRC 30
						23,00	6,50	3,50	0,20
SUPER DUPLEX UNS32750	0,030	1,20	0,035	0,020	0,80	24,00	6,00	3,00	0,24		Cu: 0,50 max	800	550	15	HRC 34
						26,00	8,00	5,00	0,32
SUPER DUPLEX UNS32760	0,030	1,00	0,030	0,010	1,000	24,00	6,00	3,00	0,20		Cu:0,50-1,00	750	550	25	HRC 32
						26,00	8,00	4,00	0,30		W:0,50-1,00

ANSI/ASME B36.10M B36.19M Dimension Coparison Table

Norminal Pipe Size	Outside Diameter	Wall Thicknesses Schedule ANSI/ASME B36.10M,B36.19M
DN(in.)	D	sch5s	sch10s	sch10	sch20	sch30	sch40s	STD	sch40	sch60	sch80s	XS	sch80	sch100	sch120	sch140	sch160	XXS
1/8	10.3	---	1.24	---	---	---	1.73	1.73	1.73	---	2.41	2.41	2.41	---	---	---	---	---
1/4	13.7	---	1.65	---	---	---	2.24	2.24	2.24	---	3.02	3.02	3.02	---	---	---	---	---
3/8	17.1	---	1.65	---	---	---	2.31	2.31	2.31	---	3.2	3.2	3.2	---	---	---	---	---
1/2	21.3	1.65	2.11	---	---	---	2.77	2.77	2.77	---	3.73	3.73	3.73	---	---	---	4.78	7.47
3/4	26.7	1.65	2.11	---	---	---	2.87	2.87	2.87	---	3.91	3.91	3.91	---	---	---	5.56	7.82
1	33.4	1.65	2.77	---	---	---	3.38	3.38	3.38	---	4.55	4.55	4.55	---	---	---	6.35	9.09
1¼	42.2	1.65	2.77	---	---	---	3.56	3.56	3.56	---	4.85	4.85	4.85	---	---	---	6.35	9.7
1½	48.3	1.65	2.77	---	---	---	3.68	3.68	3.68	---	5.08	5.08	5.08	---	---	---	7.14	10.15
2	60.3	1.65	2.77	---	---	---	3.91	3.91	3.91	---	5.54	5.54	5.54	---	---	---	8.74	11.07
2½	73	2.11	3.05	---	---	---	5.16	5.16	5.16	---	7.01	7.01	7.01	---	---	---	9.53	14.02
3	88.9	2.11	3.05	---	---	---	5.49	5.49	5.49	---	7.62	7.62	7.62	---	---	---	11.13	15.24
3½	101.6	2.11	3.05	---	---	---	5.74	5.74	5.74	---	8.08	8.08	8.08	---	---	---	---	---
4	114.3	2.11	3.05	---	---	---	6.02	6.02	6.02	---	8.56	8.56	8.56	---	11.13	---	13.49	17.12
5	141.3	2.77	3.4	---	---	---	6.55	6.55	6.55	---	9.53	9.53	9.53	---	12.7	---	15.88	19.05
6	168.3	2.77	3.4	---	---	---	7.11	7.11	7.11	---	10.97	10.97	10.97	---	14.27	---	18.26	21.95
8	219.1	2.77	3.76	---		7.04	8.18	8.18	8.18	10.31	12.7	12.7	12.7	15.09	18.26	20.62	23.01	22.23
10	273.1	3.4	4.19	---	6.35	7.8	9.27	9.27	9.27	12.7	12.7	12.7	15.09	18.26	25.4	28.58	25.4
12	323.9	3.96	4.57	---	6.35	8.38	9.53	9.53	10.31	14.27	12.7	12.7	17.48	21.44	25.4	28.58	33.32	25.4
14	355.6	3.96	4.78	6.35	7.92	9.53	---	9.53	11.13	15.09	---	12.7	19.05	23.83	27.79	31.75	35.71
16	406.4	4.19	4.78	6.35	7.92	9.53	---	9.53	12.7	16.66	---	12.7	21.44	26.19	30.96	36.53	40.49
18	457.2	4.19	4.78	6.35	7.92	11.13	---	9.53	14.27	19.05	---	12.7	23.83	29.36	34.93	39.67	45.24
20	508	4.78	5.54	6.35	9.53	12.7	---	9.53	15.09	20.62	---	12.7	26.19	32.54	38.1	44.45	50.01
22	558.8	4.78	5.54	6.35	9.53	12.7	---	9.53	---	22.23	---	12.7	28.58	34.93	41.28	47.63	53.98
24	609.6	5.54	6.35	6.35	9.53	14.27	---	9.53	17.48	24.61	---	12.7	30.96	38.89	46.02	52.37	59.54
26	660.4	---	---	7.92	12.7	---	---	9.53	---	---	---	12.7
28	711.2	---	---	7.92	12.7	15.88	---	9.53	---	---	---	12.7
30	762	6.35	7.92	7.92	12.7	15.88	---	9.53	---	---	---	12.7
32	812.8	---	---	7.92	12.7	15.88	17.48	9.53	17.48	---	---	12.7
34	863.6	---	---	7.92	12.7	15.88	17.48	9.53	17.48	---	---	12.7
36	914.4	---	---	7.92	12.7	15.88	19.05	9.53	19.05	---	---	12.7
38	965.2	---	---	---	---	---	---	9.53	---	---	---	12.7	Note: sch5s,10s,40s,80s Used for steel pipe fittings
40	1016	---	---	---	---	---	---	9.53	---	---	---	12.7
42	1066.8	---	---	---	---	---	---	9.53	---	---	---	12.7
44	1117.6	---	---	---	---	---	---	9.53	---	---	---	12.7
46	1168.4	---	---	---	---	---	---	9.53	---	---	---	12.7
48	1219.2	---	---	---	---	---	---	9.53	---	---	---	12.7

Tube Sizes for Heat Exchangers & Condensers & Boilier

Outside Diameter		BWG
		25	22	20	18	16	14	12	10
		Wall Thickness mm
		0.508	0.71	0.89	1.24	1.65	2.11	2.77	3.40
mm	inch	Weight kg/m
6.35	1/4	0.081	0.109	0.133	0.174	0.212
9.53	3/8	0.126	0.157	0.193	0.257	0.356	0.429
12.7	1/2		0.214	0.263	0.356	0.457	0.612	0.754
15.88	5/8		0.271	0.334	0.455	0.588	0.796	0.995
19.05	3/4		0.327	0.405	0.553	0.729	0.895	1.236
25.4	1		0.44	0.546	0.75	0.981	1.234	1.574	2.05
31.75	1 1/4		0.554	0.688	0.947	1.244	1.574	2.014	2.641
38.1	1 1/2		0.667	0.832	1.144	1.514	1.904	2.454	3.233
44.5	1 3/4				1.342	1.774	2.244	2.894	3.5
50.8	2				1.549	2.034	2.574	3.334	4.03
63.5	2 1/2				1.949	2.554	3.244	4.214	5.13
76.2	3				2.345	3.084	3.914	5.094	6.19
88.9	3 1/2				2.729	3.609	4.584	5.974	7.27
101.6	4					4.134	5.254	6.854	8.35
114.3	4 1/2					4.654	5.924	7.734	9.43
Stainless Steel Tube: A/SA213, A/SA269, A/SA789, EN10216-5, GOST9941-81.

Summary	Standards
Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes	ASTM A213
Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service	ASTM A269
Standard Specification For Seamless, Welded, and Heavily Cold Worked Austenitic Stainless Steel Pipes	ASTM A312
Standard Specification For Seamless Stainless Steel Mechanical Tubing	ASTM A511
Standard Specification For Seamless Stainless Steel Tubes,cold and hot finished	GOST9941-81

Standard Tolerance for Stainless Steel Seamless Pipe Tube

Standard	Outside Diameter Tolerance(mm)		Thickness Tolerance(mm)		Length Tolerance (mm)
ASTM A269	D<12.7	±0.13	±15%		+3.2 / -0
	(12.7~38.1]	±0.13	±10%
	[38.1~88.9)	±0.25			+4.8 / -0
	[88.9~139.7)	±0.38
	[139.7~203.2)	±0.76
ASTM A213	D<25.4	±0.1	D≤38.1	+20%/ -0%	D≤50.80	+3 / -0
	[25.4~38.1]	±0.15
	(38.1~50.8)	±0.2	D>38.1	+22%/ -0%	D>50.8	+5 / -0
	[50.8~63.5)	±0.25
	[63.5~76.2)	±0.30
	[76.2~101.6]	±0.38
	(101.6~190.5]	+0.38 / -0.64
	(190.5~228.6]	+0.38 / -1.14
ASTM A312	[10.29~48.26]	+0.4 / -0.8	10.3~73	+20% / -12.5%	+6 / -0
			88.9~457 T/D≤5%	+22.5% / -12.5%
	(48.26~114.30]	±0.80	88.9~457 T/D>5%	+15% / -12.5%
	(114.30~219.08]	+1.6 / -0.8	508above T/D<5%	+22.5% /-12.5%
	(219.08~457.20]	+2.4 / -0.8	508above T/D>5%	+15%/-12.5%
ASTM A789	D<12.7	±0.13	±15%		+3 / -0
	[12.7 to 38.1)	±0.13	±10%
	[38.1 to 88.9)	±0.25			+5 / -0
	[88.9 to 139.7)	±0.38
	[139.7 to 203.2)	±0.76
ГОСТ 9941-81	[5~10]	Normal:±0.30 High:±0.20 Higher:±0.15	T:0.2	Normal:±0.05; High:±0.03	/
			T:0.3~0.4	Normal:±0.07; High:±0.05
			T:0.5~1.0	Normal:±0.15; High:±0.10
	[11~30]	Normal:±0.40 High:±0.30 Higher:±0.20	T:1.2~3.0	Normal:+12.5% / -15%; High:±12.5%; Higher:+12.5% / -10%
			T:3.5~7.0	Normal:±12.5%; High:+12.5% / -10%; Higher:±10%
	[32~95]	Normal:±1.2% High:±1% Higher:±0.8%	T:7.5~8.5	Normal:+12.5% / -10%; Higher:±10%
EN10216-5	D3	±0.75% / ±0.30mm	T3	±10 / ±0.20mm	L≤6m	+5 +0
	D4	±0.5% / ±0.10mm	T4	±7.5% / ±0.15mm	≥6~12M	+10-0

Packaging & Shipping
All of our stainless steel seamless pipe & tubes are packaged as per international standard to prevent any possible damage or loss. By default, we will use thick woven plastic bag to bundle the finished pipes together in batches.
For some special pipes & tubes that are vulnerable to dirt, scratches, stress or rough handling, we will suggest wooden case for protection. Kindly note, wooden case can incur extra cost, not only its own cost, but also the increased freight cost, which is especially true for air transportation.
For enhanced customer experience, we also provide dedicated package as per your special requirements. Certifications
The inspection of our company and products is open to customers themselves or their designated third-party inspectors, such as SGS, BV, TUV, DNV, etc., who are well-known in the industry.PRODUCT APPLICATION
Petroleum IndustryChemical IndustryWater Process & TreatmentNuclear PowerBoilerHeat ExchangersShipbuilding IndustryFood processing equipmentCompany Profile
Wenzhou Guohao Steel was established in 2008. We are ISO 9001:2015 approved manufacturer, having a state-of-the-art infrastructure facility for having smooth production process. It has successfully grown by focusing on serving customers across a range of high technology industries. One of our company strengths is its people, with many colleagues having been with the company from the beginning. This provides our customers with the benefit of a wealth of experience and industry knowledge. Guohao Steel now has the whole of manufactured stainless steel products to add to its already large range of High Performance Nickel Alloys.
Guohao Steel adhere to the high standards of integrity and compliance required, including:Environmental standardsHealth and safety standardsEthical trading standardsExport compliance requirementsWe now stock and have direct access to a wide range of other materials, including stainless steels and nickel alloys. We supply and process pipes for numerous key industry sectors, collaborating with both small businesses and large international manufacturers across various countries. Due to our reputation for quality, reliability, and industry approvals, we are a well-regarded supplier in diverse sectors. Our delivery of long-term tangible benefits enables our customers to compete in today's challenging global marketplace.
In order to achieve our goals, we are improving our facilities and expanding our machinery to offer broader processing capabilities. Additionally, our investment extends to the growth and development of our teams, which represent our most valuable resource. We aim for our customers to receive the best experience and trust in the expertise, knowledge, and experience of our teams. As we continue looking towards the future, we rely on our core values to guide both decisions and actions.
Our AdvantagesMore than 16 Years of Experience in Stainless Steel Production.
Provides cost-effective products and professional services to you.
We offer an extensive range of stainless steel, super duplex steel,nickel alloy.
FAQ1.Q: Do you provide customized product services?
A: Of course, we can design and produce the products you need based on your specifications and drawings. For example: special dimensions, special controls, OEM, etc.
2.Q: Are you a manufacturer or trader?
A: We are manufacturers. We have our own factory to produce and process various kinds of stainless steel /nickel alloy pipes.
3.Q: Can we get the some samples?Is there a charge?
A: Yes, we will provide you with the samples you want. The samples are free of charge, but the customer may have to pay the freight.
4.Q: Can we visit your factory?
A: Of course, we welcome you to visit our factory on-site or visit our production line through online videos to learn more about our strength and quality. Once we have your schedule, we will arrange a professional sales team to follow up with you.
5.Q: How do you ensure the quality of the product?
A: All products must undergo three inspections throughout the entire manufacturing process, including production, cutting, and packaging. The factory inspection report is provided with the goods. If necessary, third-party inspections such as SGS can be accepted.
6.Q: What is your delivery time?
A: Different products and procurement quantities have different delivery times. The product will be delivered as soon as possible on the basis of quality assurance. Usually, if the goods are in stock, it takes 3-10 days. Alternatively, if the goods are out of stock, it will take 25 to 45 days.
7.Q: Can you arrange shipment?
A: Of course, we have freight forwarders who have been cooperating for many years. We are VIP and can provide you with the most favorable prices and professional services.
8.Q: What if I don't have import experience?
A: We have rich export experience. As long as you have an import license, please leave the rest to us! We will help you choose the most suitable transportation service to safely and accurately deliver the product to the place where it is needed.
