3t Fixed Type Electric Chain Hoist
Basic Info.
Model NO.
SSDHL 05-02
Sling Type
Chain
Lift Speed
<2m/min
Maximum Lifting Height
>20m
Chain Falls
20
Certification
CE, ISO9001:2000
Condition
New
Color
Please Offer Us The Pantone Which You Would Like
Feature
Insulating
Running Mode
Moving
Structure
Hook Crane
Installation
All-Terrain Crane
Type of Work
Middle-Level
Power Supply
3p 220V-690V
Control Voltage
24V/36V/48V
Colour
Orange,Blue,Red,Yellow
Rotation Speed
1440r/Min
ISO
M5
Transport Package
Plywood Case, Plastic Case
Specification
50ton50/20
Trademark
TXK
Origin
Jiangsu, China
HS Code
8425110000
Production Capacity
1000PCS Per Month
Product Description
3t electric chain hoist fixed type construction machineryDetails of product:
1. Electric motor partial outer cover
They are made of high strength aluminum system through compression casting formation.
Features: Solid and light, Fast release heat, Continuous use, Enclosed structure. Can be used in the chemical plants, electroplating factories, and other places.
2. Side kind braking
This masterly structure ensure the hoist absolutly safety when the power off. And ensures it is safe when has excess load. Also it combine to the motor braking as the double brake system to strengthen security and durability.
3. Gear
The gear made of alloy steel and through the heat treatment
4. Antiphase protector
Advatages: When power-supply wiring mistake, the control circuit is unable to move.
5. Hooks
They are made by hot forging and heat treatment.
6. Chain
It is made of FEC80 ultra strong heat treatment alloy steel.
Advatages: It is safely approximately when used in the rain water, the sea water, under the chemical and other bad conditions.
7. ISO: M5 /FEM: 2M
Insulation grade: F
8. Protection class (hosit and push button): IP54
9. Powder supply: 3 phase, 200-600V, 50Hz
10. Noise (single/ double speed): 81dB.
