Micro Francis Turbine
| US$2,500.00-5,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
HLD-WJ-30
Size
Micro
Type
Horizontal Hydro Generator
Bearing Support
Hanging Type
Speed
Medium Speed
Bearing Number
2
Standard
Standard
Transport Package
Wooden Case Packaging
Specification
3kw to 50 kW
Trademark
Forward Hydro
Origin
China
HS Code
8502390010
Production Capacity
1000 Units Per Year
Product Description
Micro francis turbineMicro mixed flow turbine we produced is horizontal axial arrangement type.
They are suitable for 5-30m water head, capacity 5KW-100KW. Separated generator and turbine design facilitate maintenance and spare parts replacing. Structure of turbine three bearings and generator 2 bearings makes it much more robust, and in additional turbine's individual lubricate system ensure a service life of at least 30 years. According to customer's feedback, this unit of turbine able to work three years continuously while doesn't need to change any bearing.
The generator used is brushless excitation type, which no need to change carbon brush frequently, and AVR device ensured a steady output voltage.
Technical description:
| Output | 3- 50 kW |
| Water head | 8-80m |
| Rated speed | 1000/1500 r/min |
| Generator voltage | single phase 110-200V, three phase 380-480V |
| Frequency | 50/60Hz |
| Generator | Synchronous generator |
Detailed photos:
