Concrete Machine Hb48K 48m Concrete Pump Truck

Product Description

Concrete Machine Hb48K 48m Concrete Pump Truck
I. Parts and Systems
1. Carrier
The carrier is original 4-axle chassis imported from I SUZU, Japan, designed in accordance with heavy duty chassis and suitable for tough road conditions of China construction site. It complies with Euro III emission standard.
2. Structural Parts
2.1 Placing boom
The placing boom is designed with FEM analysis and variable cross-section with equal strength, light weight; and each pivot is in optimized state with better stability, so the placing boom can be operated on narrow construction site.
2.2 Turntable
The turntable is plate frame box type structure; the steel is from Sweden Weldox900E; the upper is connected with placing boom, and the lower connected with swivel base through slewing ring; It can swing ±270°.
2.3 Swivel base
The swivel base is board frame box type structure and adopts the high strength steel. Its upper part is connected with slewing ring and the lower connected with sub-frame; the rear stabilizer and its extension cylinder are articulated on the swivel base.
2.4 Stabilizer
The front stabilizers are "X" 2-stage telescoping type and the rear stabilizer are swivel type, with the cross-section of box type reinforced structure.
2.5 Sub-frame
The sub-frame rear section has catwalks; the middle part connects with central pump water tank and the rear connects with central pump hopper and upper/lower and left/right pedals; the main frame and sub-frame are connected with each other by connection parts which are welded to the sub-frame and connected to the main frame by high-strength bolts; the sub-frame is divided into front and rear sections; the middle interval part is used for hydraulic piping.2.6 Hopper
The new type hopper has large pipe and large passing which can considerably reduce pumping resistance and increase suction sufficiency and absorption efficiency.
2.7 Delivery pipe
The passageway for concrete pumping adopts casted high wear-resistance material. With the inner surface high-frequency quenched, it has a service life of 30,000m3.
3. Slewing System
3.1 Slewing ring
The slewing ring is single-row cross roller external meshed slewing ring, made by Xuzhou R othe E rde, and can swing 360° continuously; the roller track is waterproof and dustproof.
3.2 Slewing reducer
The slewing reducer is made by famous enterprise (DINAMIC OIL, Italy) and features compact structure, heavy load bearing capacity and high power driving efficiency.
4. Central Pumping System
The central pumping system consists of pumping cylinder, water tank, concrete delivery cylinder and other parts. The pumping cylinder, water tank, concrete delivery cylinder, hopper are fixed together by lead-screws and connection bolts.

Item				Parameters and Dimensions
Overall dimesions (L× W H)			mm	12470×2500×3990
Fuel type				Diesel oil
Emission standard				NationalIII
Steering type				Steering Wheel
Number of axles				3
Wheel base			mm	4500+1350
Tire specification				315/80R22.5
Wheel track (front wheel/rear wheel)			mm	2034/1804
Complete vehicle kerb mass		Total mass	kg	32870
		Front axle	kg	6870
		Middle/rear axles	kg	26000
Maximum total mass		Total mass	kg	33000
		Front axle	kg	7000
		Middle/rear axles	kg	26000
Seating capacity of the cab			Person	2
Approach angle/departure angle				October 16
Maximum speed			km/h	80
Minimum ground clearance			mm	300
Fuel consumption per hundred kilometers				40
Chassis	Model			Actros 3341
	Manufacturer			Daimler
Engine	Model			OM501LA·III/17
	output power		kw/(r/min)	300/1800

Item			Parameters
Theoretical conveying capacity		m3/h	170
Maximum distributing height		m	47.5
Reachable distributing depth		m	34
Concrete pumping pressure		MPa	8
Maximum diameter of concrete aggregate pumping		mm	≤40
Concrete cylinder diameter/ stroke		mm	Φ260/2000
Filling height		mm	1580
Bucket capacity		m3	0.6
Concrete pumping slump scope		cm	8~23
Slewing radius of distributor boom		m	43.5
Slewing angle of distributor boom			±270°
Stretching angle of first-section boom			90°
Stretching angle of second-section boom			180°
Stretching angle of third-section boom			180°
Stretching angle of fourth-section boom			240°
Stretching angle of fifth-section boom			210°
Stretching angle of sixth-section boom			120°
Outrigger span	Longitudinal span	mm	8955
	Transverse span of front outriggers	mm	7884
	Transverse span of rear outriggers	mm	9940
Relative slewing center distance of outriggers	Transverse distance of left front outrigger	mm	3942
	Transverse distance of left rear outrigger	mm	4970
	Longitudinal distance of left front outrigger	mm	3200
Type of reversing valve			Skirt valve
Swing times of swing pipe per minute			23~26
